Teknion t-3 Adjustment Features & Instructions

SEAT HEIGHT ADJUSTMENT
To raise the chair, lift the paddle up
while lifting your weight from the
seat until you reach the desired level
and then release to lock in place. To
lower the chair, lift the paddle up
allowing your weight to push the
seat down to the desired level and
then release to lock in place.
ARM HEIGHT ADJUSTMENT
To adjust the arm height, press the
small button on the outside of
either arm to raise or lower it to the
desired position. Release the
button to lock in place.
BACK HEIGHT ADJUSTMENT
The back height adjustment is
activated by the chair's back.
To adjust the lumbar height, lean
forward and grasp both sides of the
lower portion of the outside back.
To raise, slide the back up. To
lower, slide the back all the way to
the top and then lower to desired
height. Release to lock in place.
t-3 adjustment features & instructions
The tilt control paddle on the left
locks the chair in four positions.
To adjust the recline angle, push
the paddle down to unlock it.
Recline to the desired position and
lift the paddle up to lock in place.
Lean back to determine if the
resistance is comfortable. If it is too
stiff, turn the knob counter-
clockwise to decrease tension. If it
does not
resistance, turn the knob clockwise
to increase tension.
To adjust the arm width push the
lever down and slide the arm to the
desired position. Push the lever up
to lock the arm in place.
BACK TILT ADJUSTMENT
TENSION ADJUSTMENT
provide enough
ARM WIDTH ADJUSTMENT
