Fan Motor / Fan Rotor
9. Fan Motor / Fan Rotor
Warning
Step
Remove the 2 screws
1
and remove the right
side plate.
Remove the screw and
2
remove the fan motor
fixing plate.
Loosen the lock screw
3
and remove the fan
motor.
Remove the fan rotor.
4
18
Be sure to wait for 10 minutes or more after turning off all power supplies before
disassembling work.
Procedure
Fan motor fixing plate
Lock screw
Right side
plate
(R19063)
When reassembling the fan
motor and the fan rotor,
provide as much as 5 mm
(0.2 inch) of play between
the side face of the rotor and
the bottom frame.
Side face of rotor
(R19064)
Fan motor
(R19065)
(1) Insert the fan motor with
approx. 5 mm (0.2 inch) left.
(2) Tighten the screw until it
Fan rotor
stops. Then give the screw
one more turn.
(3) Rotate the fan rotor and
confirm the fan motor and
the fan rotor are installed
appropriately.
(4) Tighten the screw
completely if appropriate.
(5) If not appropriate, go back to
(R19066)
(1).
Si041259EA
Points
Side face of
bottom frame
5 mm (0.2 inch)
(R18879)
(R9582)
