Daikin FTXM35K3V1B Removal Procedure page 16

Swing Motors
Step
6 Remove the screw
behind the drain hose,
and disconnect the
drain hose.
Remove the 2 screws
7
at the rear and on the
side of the cover link
ASSY (1).
Detach the interlock
8
shaft (2) with a flat
screwdriver, and then
detach the cover link
ASSY (1).
14
Procedure
Cover link ASSY (1)
Interlock
shaft (2)
Drain hose
(R19054)
(R19055)
(R19056)
Si041259EA
Points
Removal Procedure
