Mechanical; Environmental; Dimension Chart - DART Controls MDP CONTROL Series Instruction Manual

Mechanical

Display Type ................................................................................................................ LED, Red, 4 Digit, ½" Height
Housing Type MD10P & MD3P (with supplied gasket) .............................................................................. NEMA 4X
MD3E NEMA 4
Connector Style (pluggable connector optional) ................................................... 12-position 5mm European Style
Terminal Block Torque Setting ............................................................................................... 4.4 in. lb. Max or .5Nm
Faceplate Material .........................................................................................Polycarbonate with GE Lexan Overlay
Housing Material ........................................................................................................................................Aluminum
Length MD10P & MD3P(Required Panel Depth) ..........................................................................4.625", 117.48mm
Faceplate Width ...........................................................................................................................4.539", 115.29mm
Weight MD10P ............................................................................................................. 0.8425 lb, 13.48 oz, 382.14g
MD3P ................................................................................................................... 1.52 lb, 24.32 oz, 689.44g
MD3E................................................................................................................... 1.64 lb, 26.24 oz, 743.88g

Environmental

Operating Temperature Range ----------------------------------------------------------------------------- -10C to 45C (15F to 115F)
Operating Humidity Range ----------------------------------------------------------------------------------------- 95%, non-condensing

Dimension Chart

Model
MD10P English (inches)
Housing
Lens
MD10P Metric (millimeters)
Housing
Lens
MD3P English (inches)
Housing
Lens
MD3P Metric (millimeters)
Housing
Lens
MD3E English (inches)
Assembly
MD3E Metric (millimeters)
Assembly
Width Height
3.62 1.66
4.539 2.289
91.94 42.16
115.28 58.14
3.60 3.497
4.539 4.179
91.44 88.82
115.28 106.15
5.53 7.40
140.46 187.96
4
Depth
4.625
0.375
117.27
9.53
4.625
0.375
117.27
9.53
3.90
99.06
