DART Controls 65 series Instruction Manual

For dc input variable speed controls

Advertisement

Quick Links

CONTROLS
Instruction Manual
For DC Input Variable Speed Controls
P.0. Box 10
Phone (317) 873-5211
5000 W. 106th Street
Fax (317) 873-1105
Zionsville, Indiana 46077
www.dartcontrols.com
LT56 (IM-65E10-0303)
A-5-3180A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65 series and is the answer not in the manual?

Questions and answers

Summary of Contents for DART Controls 65 series

  • Page 1 CONTROLS Instruction Manual For DC Input Variable Speed Controls P.0. Box 10 Phone (317) 873-5211 5000 W. 106th Street Fax (317) 873-1105 Zionsville, Indiana 46077 www.dartcontrols.com LT56 (IM-65E10-0303) A-5-3180A...
  • Page 2: Table Of Contents

    WARRANTY Dart Controls, Inc. (DCI) warrants its products to be free from defects in material and workmanship. The exclusive remedy for this warranty is DCI factory replacement of any part or parts of such product which shall within 12 months after delivery to the purchaser be returned to DCI factory with all transportation charges prepaid and which DCI determines to its satisfaction to be defective.
  • Page 3: Mounting Dimensions

    MOUNTING DIMENSIONS 65E10 MOUNTING 4.250" .694" .188" DIA. (6 SLOTS) ACCEL 1.750" 3.625" IR COMP 11/32" CUR LIM SLOT DEPT TOP VIEW 1.300" .380" .315" 3.750" SIDE VIEW Caution: Do not mount controller where ambient temperature is outside the range of -10° C (15° F) to 45° (115° F). INSTALLATION Before attempting to wire the control, make sure all power is disconnected.
  • Page 4: 65E10 Hook-Up Diagram

    65E10 HOOK-UP DIAGRAM Optional Inhibit (see hook-up Min Speed below) 5KΩ Inhibit (P1-9) Speedpot Max Speed Common (P1-8) Orange Pot Low (P1-7) Pot Wiper (P1-6) Accel White Pot High (P1-5) -Arm (P1-4) I.R. Comp. +Arm (P1-3) Motor +Battery (P1-2) -Battery (P1-1) Current Limit Battery Customer supplied...
  • Page 5: Trimpot Adjustments

    • Min. or Max. trimpots not properly adjusted See “Trimpot Adjustments” - page 3-4 • Possible control failure Send to Dart Controls, Inc. Motor rotates in wrong direction • Motor armature hooked up backwards Reverse armature + and - leads Motor stalls under a light load •...
  • Page 6: Specifications

    SPECIFICATIONS 65E10 Load current (continuous) 10 amps Speed adjustment 5K Ω potentiometer or 0 to +10VDC input signal Speed range 30 : 1 Overload capacity 200% for 10 seconds; 150% for one minute Current limit adjustable 100% to 200% of full motor load, up to 200% of control current rating Acceleration adjustable - 0 to 10 seconds Deceleration...
  • Page 7 NOTES:...
  • Page 8 REPAIR PROCEDURE In the event that a Product manufactured by Dart Controls Incorporated (DCI) is in need of repair service, it should be shipped, freight paid, to: Dart Controls, Inc., 5000 W. 106th Street, Zionsville, IN. 46077, ATTN: Repair Department.
