DART Controls MDP CONTROL Series Instruction Manual page 17

Software Parameters, cont'd
Parameter Description
Signal Input #2 (S2) Setup
35 S2 Input Configuration
36 S2 Setpoint
37 S2 Pulses per Revolution
38 Front Panel DoubleClick Mode
User Input #1 (UIN1) Setup
40 UIN1 Input Configuration
41 UIN1 Setpoint for Jog
Alarm Output #1 Configuration
50 Alarm Activation Conditions
51 Output Style & Reset Mode
52 Reset Configuration
53 Display Flash On Active Alarm
54 Pulse on Time
55 Pulse off Time
56 Pulse Count
57 Lower Limit
58 Upper Limit
Parameter Memory Commands
95 Restore Settings to Factory
Default
98 Save to User Default Area
99 Restore from User Default Area
Value Range
(units)
1 – Disabled (Follower Mode)
2 – E-Stop When S2 High
3 – E-Stop When S2 Low
4 – Inhibit When S2 High
5 – Inhibit When S2 Low
6 – Jog When S2 High
7 – Jog When S2 Low
1 – 9999 (Display Units)
1 – 2048 (PPR)
0 – Hardware Inhibit
1 – DoubleClick Toggles Inhibit
1 – Disabled
2 – E-Stop When UIN1 High
3 – E-Stop When UIN1 Low
4 – Inhibit When UIN1 High
5 – Inhibit When UIN1 Low
6 – Jog When UIN1 High
7 – Jog When UIN1 Low
1 – 9999 (Display Units)
0 – Always Off
1 – Always On
2 – Active when Above upper limit
3 – Active when Below lower limit
4 – Active inside Range
5 – Active outside Range
6 – Active when Target = 0
7 – Active when no Pickup Pulses
detected
8 – Active when at Max. Conduction
1 – Constant & Auto Reset
2 – Constant & Manual Reset
3 – Pulsed & Auto Reset
4 – Pulsed & Manual Reset
1 – No Sil., Reset on Key
2 – No Sil., Reset on S2 High
3 – No Sil., Reset on S2 Low
4 – Sil., Reset on Key
5 – Sil., Reset on S2 High
6 – Sil., Reset on S2 Low
0 – Alarm Flash Disabled
1 – Alarm Flash Enabled
1 – 3600 (seconds)
1 – 3600 (seconds)
0 – 9999 (pulses)
0 – 9999 (display units)
0 – 9999 (display units)
0 – Do Nothing & Exit
5 – Restore Factory Defaults
0 – Do Nothing & Exit
5 – Save Setting
0 – Do Nothing & Exit
1 – Restore Settings
15
Factory User
Default Settings
7
1000
1
0
3
1000
0
1
1
0
1
1
0
0
9999
0
0
0
