The network module is designed to be an optional accessory that enables network capabilities for the VeriSafe 2 .0 Absence of Voltage
Tester (AVT) . The network module provides an integrated web application that is delivered by an on board web server . The web applica-
tion monitors data from the AVT and provides integration, configuration and firmware update capabilities . The network module supports
AVT data over EtherNet/IP and Modbus TCP protocols . The voltage presence discrete outputs may be used as an indication of voltage
presence with or without a network connection . The network module provides the ability to log various pieces of data based on built in
triggers (see VeriSafe Network Module User Guide, document no . B21176, for more information) .
