NETWORK COMPONENTS
CONTRACTOR GRADE
© Panduit Corp. 2013
1
Orient jack
as shown
Puck
(NKSPB)
2
1.5" (38.1mm)
Trim pair separator and/or
filler if present.
4
Option 1
T568 BA BA
(T568B shown)
** Denotes color.
For Technical Support: www.panduit.com/resources/install_maintain.asp
NetKey Category 5e, 6 & 6A Jack Modules
INSTALLATION INSTRUCTIONS
Label
Notch
CWST
Option 2
T568 BA BA
Do not untwist
more then 1/8"
from the IDC
tower
Part Number: NKP5E88M**, NK688M**, NK6X88M**
T568B
3
P4
P1
5
Page 1 of 2
Retention
Cap
T568A
P3
P4
P2
P1
(T568B shown)
PDT110
Tool
NK406C
P2
P3
