1.7 Visual signalisation

1.7.1 Mains Power LED (Attendant Control Panel)

MAINS POWER LED
lit
flashing: 0,6s lit / 0,6s not lit
flashing: 0,1s lit / 0,1s not lit
not lit

1.7.2 Accumulator Indicator (Attendant Control Panel)

ACCUMULATOR INDICATOR
lit
flashing: 1,6s lit / 0,2s not lit
flashing: 0,1s lit / 0,1s not lit
flashing: 0,2s lit / 1,6s not lit
not lit
1.7.3 Lock LED (Attendant Control Panel)
SIGNALISATION
LOCK LED
Thighrest Lock LED
Backrest Lock LED
Bed Height, Lateral Tilt, Trende-
lenburg and Antitrendelenburg Tilt
Lock LED
Foot Control Lock LED
10
VISUAL
lit 0,6s lit / 0,6s not lit
locked lock
error
locked lock
error
locked lock
error
locked lock
error
connected to the mains
keyboard error (flashing inverted to Lock LED)
error (first fault)
service mode
disconnected from the mains power
transformer switching error
accumulator disconnected or faulty
accumulator deeply discharged
accumulator discharged
accumulator is charging
accumulator charged
flashing:
not lit
keyboard motion unlocked
error blocked
keyboard motion unlocked
error blocked
keyboard motion unlocked
error blocked
keyboard motion unlocked
error blocked
MEANING
MEANING
