APPENDIX A - Model description Technical Spec.
PICO D is a continuous tunable external cavity laser. The unit is self-sustained with
respect to laser power, wavelength and temperature control electronics. However,
an external DC power supply is required to operate the laser. The PICO D is con-
trolled through its interface, having both analog (control) and digital (control and
status) signals, and requires external driver electronics for selecting output wave-
length and laser power. In order to obtain a linear behavior of the wavelength and
power control signal, they have to be externally calibrated.
PICO E can generate light in the wavelength ranges as stated below (see Specifica-
tion number 1). Specifications are given after one-hour warm-up. The PICO D can
be used before the warm up time but with limited optical specifications.
No Parameter
Tuning Range (nm)
1 CL Band
2 Mode hops
Tuning speed continuus
3
(nm / s)
Tuning speed,
4
step
Wavelength Resolution
5
(pm)
Wavelength Repeatability
6
(pm)
Absolute Wavelength
7
Accuracy (pm)
Wavelength Stability over
8
1 hour (pm)
Optical Output Power
9
(dBm over 50 nm)
Optical Output Power
10
(dBm over tuning range)
Minimum output power
11
(dBm)
12 Power resolution ( W)
Power Stability (1 hour)
13
(dB)
Min
1519 – 1630*
0-100
1 nm
10 nm
100 nm
2
0
-3 *
0.1
Typical Max
0
0-130
50 ms
30ms
150 ms
100ms
1 000
800ms
ms
0.6 1
1 2
±10
±2
10
> 2 4
-10
±0.02
Comment
The wavelength range
given by -10 and 10 V
wavelength tuning input
voltage.
(*See comment in section
4.1.1)
At 0 dBm (±0.2 dB) output
power applying a sweep
mode. (See figure in
section 4.1.2)
Including rise and settling
time
Dependent of customer
interface
Dependent of customer
interface
Constant temperature
(±0.5°C) without
wavelength locker
See section 4.1.3 for
more details
concerning Pmax
*Lower power available at
limited performance
Constant temperature (±
0.5°C)
