THORLABS PICO D User Manual page 30

Pin number
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
2.5.5.1 Power connector
The connector for the power to PICO E, Figure 2–8, comes from FCI Connectros, it
has two rows and totally 6 ways. The PCB-connector is Berg 78207-106 (drawing,
Berg 7802-106.pdf).
The mating connector is a housing for crimp terminals FCI 69176-006. Crimp termi-
nals are Mftrs No 477 46-002 for AWG 18-20 or 477 45-002 for AWG 22-26.
The Mftrs No are valid if the crimp terminals are delivered in single pieces (not as a
roll).
30
Signal name
- OPTICAL_POWER
+WAVELENGTH_TUNING
- WAVELENGTH_TUNING
Spare
Spare
Service 0
Service 0
Service 1, internal use only
Service 2, internal use only
Service 3, internal use only
Service 4, internal use only
Service 5, internal use only
Service 6, internal use only
Service 7, internal use only
Service 8, internal use only
Service 9, internal use only
Service 10, internal use only
Service 11, internal use only
Service 12, internal use only
Service 13, internal use only
Service 14, internal use only
Service 0
Service 0
Description
Analog
Analog
Analog
DO NOT CONNECT
DO NOT CONNECT
DO NOT CONNECT
DO NOT CONNECT
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
DO NOT CONNECT
DO NOT CONNECT
