Meec tools 011032 Operating Instructions Manual page 43

Cutting depth 90°
Cord length
Connection, extractor
Size
Weight
Sound pressure level, L P A
Sound power level*, L w A 107 dB(A), K = 3 dB
Always wear ear protection.
The declared values for vibration and noise,
which have been measured according to a
standardised test method, can be used to
compare different tools with each other and
for a preliminary assessment of exposure.
The measurement values have been determined
in accordance with EN 62841-3-1:2014.
WARNING!
The actual vibration and noise level when
using tools may differ from the specified
maximum value, depending on how the
tool is used and the material. It is therefore
necessary to determine which safety
precautions are required to protect the user,
based on an estimate of exposure in actual
operating conditions (taking into account all
stages of the work cycle, e.g. the time when
the tool is switched off and when it is idling,
in addition to the start-up time).
DESCRIPTION
The product is intended for rip and cross-cut
sawing (with lateral fence fitted) of all types of
wood of the shape and dimensions that suit
the product. The product is not intended for
sawing round wood of any kind.
NOTE:
The product is only intended to be used with
suitable blades (hard metal or chrome/
vanadium steel). Never use high-speed steel
blades or cutting discs. The product is not
85 mm
2 m
Ø 35 mm
94 x 64 x 83 cm
22 kg
94 dB(A), K = 3 dB
intended for commercial or industrial use.
Commercial, professional or industrial use
(or equivalent) will invalidate the warranty.
1. Power switch
2. Lock lever for bevel angle
3. Bevel angle scale
4. Knob for depth/bevel angle setting
5. Scale
6. Saw table extension
7. Mitre fence
8. Guide rail for mitre sawing
9. Blade guard
10. Splitting knife
11. Parallel fence
12. Lock lever
13. Stand
14. Reset button
FIG. 1
A. Blade guard
B. Feeder
C. Handle
D. Mitre pointer
E. Parallel fence
F. Lock lever
G. Screws and nuts
H. Spanner
FIG. 2
ASSEMBLY
WARNING!
Switch off the product, pull out the plug and
wait until all moving parts have completely
stopped before adjusting, replacing parts,
cleaning and/or carrying out maintenance.
EN
43
