Operation and Status

Connection Status - L2TP

If using L2TP, a screen like the following example will be displayed when the "Con-
nection Details" button is clicked.
Data - L2TP Screen
L2TP Status
IP Address
L2TP Server IP
DNS Server
Buttons
Connect
Disconnect
L2TP Status Screen
The IP Address of this device, as seen by Internet users. This
address is allocated by your ISP (Internet Service Provider).
The IP Address of the L2TP server.
This indicates the DNS address provided by your ISP.
If not connected, establish a connection to your ISP.
If connected to your ISP, hang up the connection.
68
