Page 1: Quick Installation Guide
WBR-3601 11g Wireless ADSL2+ Modem Router Quick Installation Guide English... -
Page 2: Default Settings
English Package Contents WBR-3601 Power Adapter (12V AC, 1A) RJ-11 ADSL / Telephone Cable RJ-45 LAN Ethernet Cable CD-ROM with Manual / Utility Quick Installation Guide If any of the above items are missing, please contact your retailer or distributor. -
Page 3: Installation
Installation 1. Connect the ADSL activated Telephone line 2. Connect the Computer LAN cable to an available LAN port. - Page 4 3. Plug in the Power Adapter 4. Press the Power ON switch on the rear of the router.
- Page 5 5. Wait until the PWR and ADSL Link lights remain lit green (not blinking) and the relevant LAN is lit. Note: If the ADSL Link light continues to blink, it means that that router cannot find an active ADSL connection. Please contact your Internet Service Provider for support.
- Page 6 Setup 1. Start your WEB browser. In the Address box, enter the following: http://192.168.0.1 2. When prompted, use the following username and password. User Name: admin Password: password...
- Page 7 3. The first time you connect to the WBR-3601, you should run the Quick Start Wizard to configure the ADSL and Internet Connection. Click Quick Start on the menu. 4. Please create a new password for the router. Leaving it as default could be a security risk.
- Page 8 IP address and related information (Network Mask, Gateway IP address, and DNS address) Bridge Mode The authentication process is not done by the WBR-3601, but by another device or PC. Note that the router and firewall functions do not apply under this mode.
- Page 9 7. When the Quick Start Wizard is complete, click “Next” to save the settings and restart the router. You will be required to enter your new password. Click “Close” to exit the Quick Start Wizard. 8. If successful, the Internet light should now be on. Now you can access the Internet.
- Page 10 9. Finally, to set up your wireless settings, please click “Interface Setup” and then “Wireless”. 10. Here you can select your Wireless ID (SSID) and the security encryption. Note: LevelOne recommends WPA2-PSK (AES) for maximum security. 11. Congratulations! Setup of WBR-3601 is now complete.
