Operation and Status

Connection Status - PPTP

If using PPTP (Peer-to-Peer Tunneling Protocol), a screen like the following exam-
ple will be displayed when the "Connection Details" button is clicked.
Data - PPTP Status Screen
Connection
IP Address
PPTP Server IP
DNS Server
Buttons
Connect
Disconnect
PPTP Status Screen
The IP Address of this device, as seen by Internet users. This
address is allocated by your ISP (Internet Service Provider).
The IP Address of the PPTP server.
This indicates the DNS address provided by your ISP.
If not connected, establish a connection to your ISP.
If connected to your ISP, terminate the connection.
67
