Use the inspections in the table below if the tool does not operate normally. If this does not remedy the
problem, consult your dealer or the HiKOKI Authorized Service Center.
1. Power tool
Symptom
Tool doesn't run
Tool suddenly stopped
Cannot be inclined
Doesn't cut well
Switch can't be pulled
Sawdust discharge is poor
Battery cannot be installed Attempting to install a battery other than
2. Charger
Symptom
The charge indicator lamp
is rapidly fl ickers purple,
and battery charging
doesn't begin.
The charge indicator lamp
blinks red, and battery
charging doesn't begin.
Battery usage time is short
even though the battery is
fully charged.

TROUBLESHOOTING GUIDE

WARNING
Possible cause
No remaining battery power
Battery isn't fully installed.
Tool was overburdened
Overload protection is in operation.
The battery is overheated.
The incline lever is not loosened.
The saw blade is worn or missing teeth.
The bolt is loose.
The saw blade is installed backwards.
The lock-off button is not pushed in
enough.
Sawdust has accumulated in the saw
cover.
that specifi ed for the tool.
Possible cause
The battery is not inserted all the way.
There is foreign matter in the battery
terminal or where the battery is attached.
The battery is not inserted all the way.
The battery is overheated.
The battery's life is depleted.
Remedy
Charge the battery.
Push the battery in until you hear a click.
Get rid of the problem causing the
overburden.
Let the battery cool down.
Try inclining after loosening the incline
lever. Tighten the loosened parts after
making the necessary adjustments.
Replace with a new saw blade.
Firmly tighten the bolt.
Install the saw blade in the proper
direction.
Push the lock-off button in all the way.
Remove the sawdust inside the saw cover.
Please install a multi volt type battery.
Remedy
Insert the battery fi rmly.
Remove the foreign matter.
Insert the battery fi rmly.
If left alone, the battery will automatically
begin charging if its temperature
decreases, but this may reduce battery
life. It is recommended that the battery be
cooled in a well-ventilated location away
from direct sunlight before charging it.
Replace the battery with a new one.
