Specifications - HIKOKI C 3607DWA Handling Instructions Manual

2. Battery (sold separately)
Ventilation holes
Battery

SPECIFICATIONS

1. Cordless Rear Handle Circular Saw
Model
Voltage
Motor
No-load speed
Blade Size
Max. Cutting Depth
Max. Blade Angle
Type*
Power supply
Voltage
Weight
* Existing batteries (BSL3660/3626/3620, BSL18xx and BSL14xx series, etc.) cannot be used with this tool.
2. Battery Charger (sold separately)
Model
Charging time
(At a temperature of 20°C)
Charging voltage
Charging current
Weight
NOTE: The charging time may vary according to temperature and power source voltage.
Battery cover
Terminals
Latch
<BSL36B18>
Fig. 7
3. Battery Charger (sold separately)
Cord
Body
Nameplate
<UC18YSL3>
C3607DWA
36 V
DC brushless motor
5,100 /min
185 mm D × 20 mm H
62 mm
Adjustable 0°–53°
Li-ion battery Model BSL36B18
36 V
4.7 kg (BSL36B18 attached)
UC18YSL3
BSL36B18 : Approx. 52 min
DC 14.4–18 V
DC 8.0 A
0.6 kg
Charge indicator lamp
Ventilation holes
Guide rail
Fig. 8
11
