EventMOVE 4/4

DMX Channels

6 channels

Channel 1 – Red
0-255 Gradual adjustment Red, from dark to brightest
Channel 2 – Green
0-255 Gradual adjustment Green, from dark to brightest
Channel 3 – Blue
0-255 Gradual adjustment Blue, from dark to brightest
Channel 4 – White
0-255 Gradual adjustment White, from dark to brightest
Channel 5 – Vertical movement (Tilt)
Move the slider up, in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 6 – Tilt speed
0-255 From Max Speed (0) to Min. Speed (255)
8 channels
Channel 1 – Dimmer
0-255 Dimmer intensity, from dark to bright
Channel 2 – Strobe
0-255 Strobe flash frequency, from OFF to highest frequency
Channel 3 – Red Dimmer must be open
0-255 Gradual adjustment Red, from dark to brightest
Channel 4 – Green
0-255 Gradual adjustment Green, from dark to brightest
Channel 5 – Blue Dimmer must be open
0-255 Gradual adjustment Blue, from dark to brightest
Channel 6 – White
0-255 Gradual adjustment White, from dark to brightest
Channel 7 – Vertical movement (Tilt)
Move the slider up, in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 8 – Tilt speed
0-255 From Max Speed (0) to Min. Speed (255)
Ordercode: 44020
Dimmer must be open
Dimmer must be open
Dimmer must be open
