Setup and installation

Connect and turn on
CAUTION: Do not disconnect a device under test when the instrument is powered on. If a disconnection occurs when power is
on, the instrument must be powered off, and then powered back on after DUT connectivity is restored.
Follow these steps after you unpack the instrument to turn it on, connect, and get started. This requires an Ethernet connection.
1. Plug in an Ethernet cable to the LAN connector on the rear panel of the instrument and then directly to the host PC or to an Ethernet
network.
2. Plug in the supplied power cord to the power connector on the rear of the instrument and to an appropriate power source.
3. Push the Power button on the front panel to turn on the instrument. The Power button LED color indicates the power mode of the
instrument. Amber is Standby. Blue is On. No light means the instrument is unplugged and Off.
4. When you are turning on the instrument for the first time, the following screen should appear. Write down the IP address shown on the
screen of your instrument.
5. Open a browser window on a PC and enter the IP address from your instrument.
6. Enter the serial number of your instrument into the Factory Password field. Then enter a new password in the New Password field.
Re-enter the password. Be sure to remember the new password or record and place it in a secure location. It will be needed each time
the instrument is remotely accessed.
