Key features

• PCIe Gen 3 (8 GT/s) and Gen 4 (16 GT/s) speeds supported
• Link widths up to 16 lanes supported
• Support for CEM, M.2, U.2, and U.3 devices
• Two scan options: Quick Scan and Custom Scan
• DUT transmitter (Tx) eye diagrams and link training parameters for each lane tested
• DUT functional receiver (Rx) evaluation for each lane tested

Documentation

Product documentation
The following table lists the primary product specific documentation available for your product. These and other user documents are
available for download from tek.com. Other information, such as demonstration guides, technical briefs, and application notes, can also be
found at tek.com.
Document
Installation and Safety Instructions
User
Specifications and Performance Verification Technical Reference
API commands
Declassification and Security Instructions
How to find your product documentation
1. Go to tek.com.
2. Click Download in the green sidebar on the right side of the screen.
3. Select Manuals as the Download Type, enter your product model, and click Search.
4. View and download your product manuals. You can also click the Product Support Center and Learning Center links on the page for
more documentation.

Power, environmental, and physical specifications

Power
Input voltage
Frequency
Power
WARNING: To reduce the risk of fire and shock, ensure that the mains power supply voltage fluctuations do not exceed 10% of
the operating voltage range.
TMT4 Margin Tester User Manual
Content
Safety, compliance, and basic introductory information for hardware
products.
Operating information, including API usage, for the product.
Instrument specifications and performance verification instructions
for testing instrument performance.
API commands for remotely controlling the instrument are available
from the instrument IP address in the Web browser.
Information about the location of memory in the instrument.
Instructions for declassifying and sanitizing the instrument.
100-240 V
50-60 Hz
200 W maximum
Key features
