Concept2 RM7000 Manual page 57

OPERATING INSTRUCTIONS
Whipping, kneading and blending
IMPORTANT
• If the back cover of the appliance is not in place, the appliance will not work.
• DO NOT attempt to use this function while grinding or blending.
1. Place the mixing container in the base and turn it clockwise until it clicks into place.
2. To raise the arm, press the release button (8) and at the same time lift the arm by gently pulling it up.
3. Place the lid (6) on the container and turn it clockwise until it clicks into place.
4. Place the desired whisk on the output shaft, push the whisk against the spring gently and turn it until it locks into
the lock.
5. Now put the ingredients in the container. Do not exceed the maximum allowable amount of ingredients, which is
1.1 kg.
6. Release the arm with the release button (8) while lowering it with a slight pressure.
7. Insert the plug into the wall outlet.
8. Switch on the appliance and turn the speed control button (4) to select a speed between 1 and 5 (depending on the
type of dough being prepared).
9. Pulse operation (kneading at short intervals): turn the speed control button to the "PULSE" position. When the switch
is released, it automatically returns to the "OFF" position.
10. After mixing is complete, turn the speed control button (4) to the "OFF" position. Then remove the plug from the
wall outlet.
11. Press the release button (8) and at the same time lift the arm by gently pulling it up.
12. The container can now be removed.
13. Remove the mixture from the container with a spatula.
14. Cleaning is described in the "Cleaning" chapter.
Setting the speed and using the whisks. The maximum quantity of the mixture must not exceed 1.1 kg.
Speed
1-2 Dough hook
3-4 Mixing whisk
5 Whisk
Pulse Whisk
NOTE:
Do not exceed the maximum continuous operating time (KB max), see the table of technical parameters.
Leave the motor off for at least 20 minutes before using the appliance again.
Speed setting and display operation for RM7500 and RM7510 models.
The RM7500/RM7510 models have a touch screen display:
3
RM7000 | RM7010 | RM7020 | RM7030 | RM7500 | RM7510
Use
1
2
4
5
6
Type of mixture
Dense mixtures (e.g. bread dough, pizza, yeast dough)
Medium dense mixtures (e.g. pancake mixture, rubbed
dough, butter creams)
Light mixtures (e.g. cream, egg white, pudding)
Short-term whipping (e.g. whipped cream)
1. Accessories (When changing the speed, only the
accessories optimal for the selected speed are
displayed.)
2. Speed 1-6 (Speed 7 is for the mixer only.)
3. Speed/time reduction
4. Speed/time increase
5. Time
6. ON/OFF
