G730-Install-IG100 Installation Guide
Table 13: SFP-DD Port Status LED Patterns during Normal Operation
LED Color
No light (LED is off)
Steady green
Slow-flashing green (on for 2 seconds; then
off for 2 seconds)
Fast-flashing green (on for 1/2 second; then
off for 1/2 second)
Flickering green
Steady amber
Slow-flashing amber (on for 2 seconds;
then off for 2 seconds)
Fast-flashing amber (on for 1/2 second;
then off for 1/2 second)

Interpreting Nonport-Side LEDs

The following figure shows the LEDs on the nonport side of the switch.
Figure 39: Brocade G730 Nonport-Side LEDs
1. Power Supply DC Status LED
2. Power Supply AC Status LED
3. Fan Assembly Status LED
Hardware Status
The port has no incoming power, or there is
no light or signal carrier detected.
The port is online (connected to an external
device) but has no traffic.
The port is online but is segmented
because of a loopback cable or
incompatible device connection.
The port is online, and an internal loopback
diagnostic test is running.
The port is online with traffic flowing
through the port.
The port is receiving light or signal carrier,
but it is not online yet.
The port is disabled because of diagnostic
portDisable
tests or the
The transceiver or port is faulty.
Brocade
Verify that the power LED is on, and check
the transceiver and cable.
No action is required.
Verify that the correct device is attached to
the switch.
No action is required.
No action is required.
No action is required.
Reset the port from the workstation.
command.
Reset the transceiver or reset the port from
the workstation.
®
G730 Switch Hardware Installation Guide
Recommended Action
G730-Install-IG100
63
