2.4

Accelerometer and gyroscope: ISM330DHCX

The ISM330DHCX
digital gyroscope tailored for Industry 4.0 applications. The sensing elements of the accelerometer and of the
gyroscope are implemented on the same silicon die, thus guaranteeing superior stability and robustness.
The ISM330DHCX
±125/±250/±500/±1000/±2000/±4000 dps that enable its usage in a broad range of applications.
An unmatched set of embedded features (machine learning core, programmable FSM, FIFO, sensor hub, event
decoding, and interrupts) enable the implementation of smart and complex sensor nodes, which deliver a high
performance at very low power.
All the design aspects and the calibration of the
stability, extremely low noise, and full data synchronization.
The ISM330DHCX
connected via an I²C auxiliary bus. Various configurations are possible for different I²C bus connections with or
without the ISM330DHCX
UM3076 - Rev 1
Figure 7.
is a system-in-package featuring a high-performance 3-axis digital accelerometer and 3-axis
has a full-scale acceleration range of ±2/±4/±8/±16 g and a wide angular rate range of
Table 5.
Features
Order code
Package
Operating voltage
has an I²C sensor hub, which allows it to behave as the I²C master for other slave devices
sensor hub.
Accelerometer and gyroscope: ISM330DHCX
ST2378ETTR circuit
ISM330DHCX details
ISM330DHCX have been optimized to reach superior accuracy,
UM3076
Description
ISM330DHCXTR
14-LGA
1.71 V to 3.6 V
page 8/38
