Time-of-Flight sensor: VL53L5CX

The VL53L5CX
reflowable package. It integrates a SPAD array, physical infrared filters, and diffractive optical elements (DOE) to
achieve the best ranging performance in various ambient lighting conditions with a range of cover glass materials.
This sensor uses the direct ToF technology to allow absolute distance measurement whatever the target color and
reflectance. It provides accurate ranging up to 400 cm and can work at fast speeds (60 Hz).
Insert the following information of the ToF sensor:
The VL53L5CX
• laser wavelength: 940 nm
• invisible laser radiation
• maximum laser power emitted: 130 mW
• pulse duration: 2 ns with intervals of 28/32 ns
UM3076 - Rev 1
Table 10.
Features
Order code
Package
Operating voltage
Figure 13.
is a state of the art, Time-of-Flight (ToF), multizone ranging sensor, housed in a miniature
characteristics are:
Table 11.
Features
Order code
Package
Operating voltage
STTS22HTR details
STTS22HTR circuit
VL53L5CX details
Description
VL53L5CXV0GC/1
Optical LGA16
1.8 V to 3.3 V
UM3076
Time-of-Flight sensor: VL53L5CX
Description
STTS22HTR
6-UDFN
1.5 V to 3.6 V
