2.5

Linear accelerometer: IIS2DLPC

The IIS2DLPC
interface, which leverages on the robust and mature manufacturing processes already used for the production
of micromachined accelerometers. The
capable of measuring accelerations with output data rates from 1.6 Hz to 1600 Hz.
The IIS2DLPC
wakeup, highly configurable single/double-tap recognition, activity/inactivity, stationary/motion detection, portrait/
landscape detection, and 6D/4D orientation. It features a data-ready signal, which indicates when a new set of
measured acceleration data is available, thus simplifying data synchronization in the digital system that uses the
device.
2.6

Magnetic sensor: IIS2MDC

The IIS2MDC
field dynamic range up to ±50 gauss.
UM3076 - Rev 1
Figure 8.
is an ultra-low-power high-performance three-axis linear accelerometer with digital I²C/SPI output
IIS2DLPC
has dedicated embedded features to process motion and acceleration detection including free-fall,
Table 6.
Features
Order code
Package
Operating voltage
Figure 9.
is a high-accuracy, ultra-low-power 3-axis digital magnetic sensor. The
ISM330DHCXTR circuit
has user-selectable full scales of ±2g/±4g/±8g/±16g and is
IIS2DLPCTR details
IIS2DLPCTR circuit
UM3076
Linear accelerometer: IIS2DLPC
Description
IIS2DLPCTR
12-LGA
1.62 V to 3.6 V
IIS2MDC has a magnetic
page 9/38
