2

Component description

2.1

EEPROM: M24C32-R

The M24C32-R
voltage from 1.8 V to 5.5 V
The EEPROM communicates with the
enable feature on the device. You can perform the read and write operation by setting the jumper as detailed in
the following table.
2.2

40-pin GPIO connector

The on-board devices are controlled through the main board using various peripheral pins available on a 40-pin
GPIO connector. The series resistors are used to isolate the pins of the GPIO connector.
UM3076 - Rev 1
is a 32-Kbit I²C-compatible EEPROM, organized as 4 K × 8 bits. It can operate with a supply
Table 1.
Features
Order code
Package
Operating voltage
X-STM32MP-MSP01
Table 2.
Jumper
1-2
2-3 (default)
Figure 5.
EEPROM details
M24C32-RMN6TP
through I²C signals. The J4 jumper enables the write
EEPROM jumper details
EEPROM
WRITE_ENABLE
WRITE_DISABLE
EEPROM section
UM3076
Component description
Description
SO8
1.8 V to 5.5 V
page 5/38
