NFC tag: ST25DV64KC

The ST25DV64KC
(EEPROM) with two interfaces. The first one is an I²C serial link and can be operated from a DC power supply.
The second one is an RF link activated when it acts as a contactless memory powered by the received carrier
electromagnetic wave. In the I²C mode, the
split into four flexible and protectable areas.
A GPO pin for interruption pin configurable on multiple RF events (field change, memory write, activity, Fast
Transfer end, user set/reset/pulse) is available.
As the ST25DV64KC
It is tuned to work at 13.56 Mhz. There is no channel.
The reader emits a 13.56 radio frequency.
The ST25DV64KC
UM3076 - Rev 1
Figure 16.
is NFC RFID tag that includes 64‑Kbit of electrically erasable programmable memory
ST25DV64KC
Table 13.
Features
Order code
Package
Operating voltage
Figure 17.
is a tag, it does not generate any power. It is activated with the power of a reader.
is powered by this electromagnetic field and modulates it to exchange data.
VD6283TX circuit
user memories contain 8192 bytes, which could be
ST25DV64KC details
Description
ST25DV64KC-IE6S3
1.8 V to 5.5 V
ST25DV64KC circuit
UM3076
NFC tag: ST25DV64KC
8-SOIC
