SOM-MZ10
Startup Manual
Product Information
• Supports 11th Gen Intel® Core™ platform
• Power SPEC:
SW1-2: 8.5 ~ 20V
SW 2-3: 20V
• Display SPEC: 4096x2304 60Hz 36bpp; 5120x3200 60Hz
24bpp
I
Connector List
Connectors
Label
Function
When the SW3 switch is set to
1-2, it supports Type C display and
thunderbolt device functions
USB 1
When the SW3 switch is set to 2-3,
this port must be plugged into a
Type C adapter, or into a port which
can provide power
Supports Type C display functions
USB 2
and thunderbolt device
SSOM1-AB/CD
Plugged into the COM module
SSOM2-AB/CD
Plugged into the carrier board
For more information about this and other Advantech
products, visit our website at
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and customer service, visit our
support website at
http://support.advantech.com
This manual is for the SOM-MZ10 Series.
Part No. 2046MZ1000
Printed in China
1.1 Product information
1.1 Product information
 Support TigerLake platform
 Power SPEC:
 Support TigerLake platform
SW1-2
 Power SPEC:
8.5-20V
SW1-2
Connector Locations
8.5-20V
 Display SPEC: 4096x2304 60Hz 36bpp; 5120x3200 60Hz 24bpp
 Display SPEC: 4096x2304 60Hz 36bpp; 5120x3200 60Hz 24bpp
1.2 Connector Location
1.2 Connector Location
USB1
USB1
Edition 1
Nov. 2021
SW 2-3
20V
SW 2-3
20V
Figure 1. Connector Locations (Top)
SOM-MZ10 Top side
SOM-MZ10 Top side
SOM-MZ10 Bottom side
SOM-MZ10 Bottom side
Figure 2. Connector Locations (Bottom)
SOM-MZ10 Startup Manual 1
USB2
SW3
USB2
SW3
SSOM1-AB
SSOM1-AB
SSOM1-CD
SSOM1-CD
SSOM2-AB
SSOM2-AB
SSOM2-CD
SSOM2-CD
