  • Page 1 User Manual SOM-5899Refresh Arrow.com. Downloaded from...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 Class I, Division 2, Groups A, B, C and D indoor hazards. Technical Support and Assistance Visit the Advantech website at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
  • Page 4 Document Feedback To assist us in making improvements to this manual, we welcome comments and constructive criticism. Please send all such, in writing, to: support@advantech.com Packing List Before setting up the system, check that the items listed below are included and in good condition.
  • Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 6 PC is on. Disconnect power before making any configuration changes. The sudden rush  of power resulting from connecting a jumper or install a card may damage sensi- tive electronic components. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 7 Power Management..............9 1.3.10 Environment.................. 9 1.3.11 MTBF ..................10 1.3.12 OS Support (duplicate with SW chapter) ........10 1.3.13 Advantech iManager ..............10 1.3.14 Power Consumption..............11 1.3.15 Performance ................12 1.3.16 Selection Guide w/ P/N ............... 12 1.3.17 Packing list.................. 12 1.3.18 Development Board ..............
  • Page 8 Installation..83 S/W Introduction ..................84 Driver Installation ..................84 4.2.1 Windows Driver Setup ..............84 4.2.2 Other OS..................84 Advantech iManager ................84 Appendix A Assignment......... 87 SOM-5899 Type 6 Pin Assignment............88 Appendix B Watchdog Timer........ 93 Programming the Watchdog Timer ............94...
  • Page 9 Chapter General Information This chapter gives background information on the SOM-5899Re- fresh CPU Computer on Module Sections include:  Introduction  Functional Block Diagram  Product Specification Arrow.com. Downloaded from...
  • Page 10 Introduction The SOM-5899Refresh series is equipped with 9th Gen Intel® Core™/Xeon Product Family 14nm processor technology. This product supports 1.2V power design DDR4 2666MT/s, a 96GB capacity, and ECC memory with specific SKU. SOM-5899Refresh facilitates a higher memory bandwidth - featuring an i7-9850HE SKU upgrade to hex- acore for enhanced computing performance.
  • Page 11 Serial Presence Detect - refers to serial EEPROM on DRAMs that has DRAM Module configuration information Trusted Platform Module, chip to enhance the security features of a computer system UEFI Unified Extensible Firmware Interface Watchdog Timer SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 12 Functional Block Diagram SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 13 Thermal Protection Lid Input Battery Low Alarm Suspend/Wake Signals Fan PWM / Tachometer Trusted Platform Modules Display Digital Display Interfaces 1 - 3 PEG (PCI Express x16) PCI Express x1 USB 3.0 Rapid Shutdown SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 14 1.3.4 Memory There are a total of 3 memory sockets on SOM-5899Refresh, supporting a 96GB capacity (utilizing ECC memory modules with specific SKU), 2 DDR4 260pin SOD- IMM sockets, different channels on the front side (dual-channel), and 1 socket DDR4 SODIMM on the reverse side.
  • Page 15 1.3.8.3 USB 3.0 (3.1)/USB 2.0 COM-Express supports USB 3.0 but SOM-5899Refresh supports 4 USB 3.1 Gen2 (10 Gbps) ports and 4 USB 2.0 (480 Mbps) ports which are reverse compatible to USB1.x. For USB 3.1, product supports LPM (U0, U1, U2, and U3) for power effi- ciency.
  • Page 16 SPI_CS0# to Carrier Board, SPI_CS1# to Module SPI_CS0# to Module, SPI_CS1# to Carrier Board Note! If system COMS is cleared, Advantech strongly suggests going to the BIOS setup menu and loading default settings on the first boot up. 1.3.9 Power Management 1.3.9.1...
  • Page 17 1.3.12 OS Support (Repeated in S/W chapter) The mission of Advantech Embedded Software Services is to "Enhance quality of life with Advantech platforms and Microsoft Windows Embedded technology." We enable Windows Embedded software products on Advantech platforms to more effectively support the embedded computing community.
  • Page 18 Idle mode: DUT power management off and not running any program  OS: Windows 10 Enterprise 1.3.15 Performance To compare performance or benchmark data with other modules, please refer to “Advantech COM Performance & Power Consumption Table.” SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 19 I3-9100HL 1.6 QM370 non-ECC Active -40~85 °C S6A1 1.3.17 Packing List Part No. Description Quantity SOM-5899Refresh CPU module 1960081253T001 Heatspreader of SOM-5899Refresh 1.3.18 Development Board Part No. Description SOM-DB5830-00A1 COMe level. Board COMe R3.0 Type6 pint-out (SOM-DB5830) 1.3.19 Optional Accessories Part No.
  • Page 20 1.3.20 Pin Description Advantech provides useful checklists for schematic design and layout routing. Sche- matic checklists will specify details about each pin’s electrical properties and how to connect them in different user scenarios. The layout checklist will specify the layout constraints and recommendations for trace length, impedance, and other relevant information during design.
  • Page 21 Chapter Mechanical Information This chapter details mechanical information on the SOM- 5899Refresh CPU Computer on Module Sections include:  Board Information  Mechanical Drawing  Assembly Drawing Arrow.com. Downloaded from...
  • Page 22 Board Information The figures below show the location of the main chips on the SOM-5899Refresh Computer-on-Module. When designing customized boards, be aware of positioning to avoid contact with thermal solutions and other components for optimal performance. Smart Fan Connector Generation 9 Intel®...
  • Page 23 Wafer 2.0mm (.86in) 3P 90D (M) DIP 2001-WR-03-LF W/Lock Pin Name Fan Tach-Input Fan Out Mechanical Diagram For more details regarding 2D/3D models, please visit the Advantech COM support service website: http://com.advantech.com. 59.95 40.55 30.15 Figure 2.3 Board Mechanical Diagram – Front SOM-5899Refresh User Manual Arrow.com.
  • Page 24 Figure 2.4 Board Mechanical Diagram – Rear 9.20 Figure 2.5 Board Mechanical Diagram – Side SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 25 These figures demonstrate the order of assembly for attaching the thermal module and COM module to carrier board. Semi-cooler Heat Spreader SOM-5899Refresh SOM-DB5830 Figure 2.6 Assembly Diagram There are 5 reserved screw holes for SOM-5899Refresh to be pre-assembled with the heat spreader. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 26 Please consider the CPU and chip height tolerance when designing your thermal solution. Figure 2.7 CPU 6C + GT2 Height and Tolerance (For all other SKUs please contact Advantech’s sales team or FAE for more details) Figure 2.8 PCH Height and Tolerance Diagram  ...
  • Page 27 Chapter AMI BIOS This chapter details BIOS setup information for the SOM-5899Re- fresh CPU Computer-on Module Sections include:  Introduction  Entering Setup  Hot/Operation Key  Exit BIOS Setup Utility Arrow.com. Downloaded from...
  • Page 28 Starting The SOM-5899Refresh BIOS is stored on a flash ROM which can be inserted into a BIOS socket on the board. Users can modify BIOS settings and control various sys- tem features with the BIOS Setup program. This chapter describes the basic naviga- tion of the SOM-5899Refresh BIOS setup screens.
  • Page 29 Enter Entering sub-menu or display option items. SOM-5899Refresh BIOS has a built-in setup program that allows users to modify the basic system configuration. This information is stored in flash ROM so it retains the Setup information when the power is turned off.
  • Page 30 Displays this BIOS supporting industry stan- Compliance No Option dards compliance. Displays the project version of Advantech Project Version No Option projects. Build Date and Time No Option Displays this BIOS build date and time. Access Level No Option Please refer to session "3.1.4 Security".
  • Page 31 3.1.2 Advanced BIOS Features Setup Select the Advanced tab from the SOM-5899Refresh setup screen to enter the Advanced BIOS Setup screen. Users can select any item in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. Users can display an Advanced BIOS Setup options by highlighting them using the <Arrow>...
  • Page 32 ACPI Lower Power S0 Idle Capabil- Disabled ity (Mutually exclusive with Smart con- Low Power S0 Idle Capability Enabled nect). While this is enabled, it also disables the 8254 timer for SLP_S0 sup- port. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 33 Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technol- Disabled Hyper-Threading ogy) and Disabled for other OS (OS not Enabled optimized for Hyper-Threading Technol- ogy). Disabled Enable/Disable AES (Advanced Encryp- Enabled tion Standard). SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 34 3.1.2.3 Power & Performance Feature Options Description CPU - Power Management Control CPU - Power Management Control <Sub Menu> Options. GT - Power Management Control GT - Power Management Control <Sub Menu> Options. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 35 Turbo Performance Intel® Speed- Disabled Allows more than two frequency ranges to Step™ Enabled be supported. Disabled Enable/Disable processor Turbo Mode Turbo Mode Enabled (requires Intel Speed Step or Intel SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 36 GT - Power Management Control  Feature Options Description RC6 (Ren- Disabled Check to enable render standby sup- der Standby) Enabled port. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 37 When Disabled ME will not be unconfig- ME Unconfig on RTC Clear Enabled ured on RTC Clear. Configure Management Engine Tech- Firmware Update Configuration <Sub Menu> nology Parameters. Check to enable render standby sup- PTT Configuration <Sub Menu> port. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 38 AMT Configuration  Feature Options Description Disabled Enable/Disable Alert Standard Format ASF support Enabled support. Disabled Enable/Disable of AMT USB Provi- USB Provisioning of AMT Enabled sioning. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 39 MEBx Setup. OEM defined timeout for MPS connec- tion to be established. 0 - use the default timeout value of 60 CIRA Timeout No Options seconds. 255 - MEBx waits until the connection succeeds. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 40 Watchdog Timer Enable/Disable Watchdog Timer. Enabled OS Timer No Option Set OS Watchdog timer. BIOS Timer No Option Set BIOS Watchdog timer. Disabled Adds ASF Sensor Table into ASF! ASF Sensors Table Enabled ACPI Table. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 41 Secure Erase Configuration  Feature Options Description Simulated Secure Erase Configuration Secure Erase configuration menu. Real Disabled Force Secure Erase Force Secure Erase on next boot. Enabled SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 42 ME uncon- figuration. Disabled OEMFlag Bit 14: MEBx OEM Debug Menu Enable Enabled Enable OEM debug menu in MEBx. OEMFlag Bit 15: Disabled Unconfigure ME Unconfigure ME with resetting Enabled MEBx password to default. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 43 Description Auto Non-UI Mode Resolution 80x25 Resolution for non-UI text mode. 100x31 Auto UI Mode Resolution 80x25 Resolution for UI text mode. 100x31 Auto 640x480 Graphics Mode Resolution Resolution for graphics mode. 800x600 1024x768 SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 44 Firmware Update Configuration  Feature Options Description Disabled Enable/Disable Me FW Image Re- Me FW Image Re-Flash Enabled Flash function. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 45 Selects TPM device: PTT or dTPM. PTT - Enables PTT in SkuMgr dTPM 1.2 - dTPM TPM Device Selection Disables PTT in SkuMgr Warning! PTT/ dTPM will be disabled and all data saved on it will be lost. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 46 Trusted Computing Feature Options Description Enables or Disables BIOS Support for Disabled security device. O.S. will not show Security Device Support Enabled security device. TCG EFI protocol and INT1A interface will not be available. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 47 Select the highest ACPI sleep state the Suspend Disabled S3 (Sus- ACPI Sleep State system will enter when the SUSPEND pend to RAM) button is pressed. Disabled S3 Video Repost Enable or Disable S3 Video Repost. Enabled SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 48 Select Power Saving Mode. Deep Sleep Serial Port 1 Config- <Sub Menu> Set Parameters of Serial Port 1 (COMA). uration Serial Port 2 Config- <Sub Menu> Set Parameters of Serial Port 2 (COMB). uration SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 49 Enable or Disable Serial Port (COM). Enabled Device Settings No Option Device settings for Super IO Device. I/O=3F8h; IRQ=4; I/O=2F8h; IRQ=4; Select an optimal setting for Super I/O Change Settings I/O=3E8h; IRQ=4; Device. I/O=2E8h; IRQ=4; SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 50 Enable or Disable Serial Port (COM). Enabled Device Settings No Option Device settings for Super I/O Device. I/O=3F8h; IRQ=3; Change Settings I/O=2F8h; IRQ=3; Select an optimal settings for Super I/ I/O=3E8h; IRQ=3; O Device. I/O=2E8h; IRQ=3; SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 51 Shows the current status. Carrier Board FAN No option Shows the current status. +12V No option Shows the current status. + 5V No option Shows the current status. VBAT No option Shows the current status. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 52 ANSI: Extended ASCII char set. VT100 VT100: ASCII char set VT100+ Terminal Type VT100+: Extends VT100 to support VT-UTF8 color, function keys, etc. ANSI VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 53 Recorder Mode Enabled sent. This is to capture Terminal data. Disabled Enables or disables extended terminal Resolution 100x31 Enabled resolution VT100 LINUX XTERMR6 Select Function key and keypad on Putty Keypad Putty. ESCN VT400 SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 54 Console Redirection Settings (EMS) Feature Options Description Microsoft Windows Emergency COM1 Management Services (EMS) COM2 Out-of-Band Mgmt Port allows for remote management of COM2(Pci Bus0,Dev0,Func0) a Windows Server OS through a (Disabled) serial port. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 55 Stop bits indicate the end of a serial data packet. (A start bit indi- cates the beginning). The standard Stop Bits No Option setting is 1 stop bit. Communica- tion with slow devices may require more than 1 stop bit. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 56 Host Con- Auto Device power-up delay troller. 'Auto' uses default value: for a Root Manual port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 57 3.1.2.10 Network Stack Configuration SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 58 PXE boot. Use either +/- or numeric keys to set the value. Number of times the presence of media Media detect count 1~50 will be checked. Use either +/- or numeric keys to set the value. 3.1.2.11 CSM Configuration SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 59 UEFI SMM. This is optional and highly chipset- and plat- form-specific. An example of such a legacy SMM functionality is providing USB legacy support for keyboard and mouse, by emulating their classic PS/2counterparts. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 60 3.1.2.12 NVMe Configuration NVMe Device Options Settings SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 61 3.1.3 Chipset Select the Chipset tab from the SOM-5899Refresh setup screen to enter the Chipset BIOS Setup screen. You can display a Chipset BIOS Setup option by highlighting it using the <Arrow> keys. All plug-and-play BIOS Setup options are described in this section.
  • Page 62 PEG Port Options. Configuration Disabled VT-d VT-d capability. Enabled Enable/Disable above 4GB Memory- Above 4GB MappedIO BIOS assignment. Disabled MMIO BIOS This is enabled automatically when Enabled Assignment Aperture Size is set to 2048MB. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 63 This page shows memory information. Feature Options Description Dynamic 3.5GB 3.25GB 2.75GB Maximum Value of TOLUD. Dynamic 2.5GB assignment would adjust TOLUD Max TOLUD 2.25GB automatically based on largest MMIO length of installed graphic controller 1.75GB 1.5GB 1.25GB SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 64 PEG Eval: DGPU Power Enable = ActiveHigh. Auto Internal Keep IGFX enabled based on the Disabled Graphics setup options. Enabled GTT Size Select the GTT Size. 128MB 256MB Aperture Size 512MB Select the Aperture Size. 1024MB 2048MB SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 65 128M Select DVMT5.0 Total Graphic Mem- DVMT Total 256M ory size used by the Internal Graphics Gfx Mem Device. Disabled PM Support Enable/Disable PM Support Enabled Disabled PAVP Enable Enable/Disable PAVP Enabled LCD Control SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 66 1920x1080 Customize Disabled Intel(R) Ultrabook Event Support PEG Port Configuration Feature Options Description IUER Slate Disabled Enable/Disable IUER Slate Function- Enable Enabled ality. IUER Dock Disabled Enable/Disable IUER Dock Function- Enable Enabled ality. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 67 Select the scale used for the Slot Power Scale 0.01x Limit Value. 0.001x Set the physical slot number attached to PEG0 Physical Slot Num- 0~8191 be globally unique within the chassis Val- ues 0-8191. PEG 0:1:1 SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 68 Enabled: PCIe ASPM will be pro- Program PCIe ASPM After grammed after OpROM. OpROM Disabled: PCIe ASPM will be pro- grammed before OpROM. PCIe Spread Spectrum Allows disabling Spread Spectrum Clock- Clocking ing for compliance testing. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 69 PEG Port Feature Configuration Feature Options Description Disabled Detect Non-Compliance PCI Express Detect Non-Compliance Device Enabled Device in PEG. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 70 Quiet Serial IRQ Mode Config Serial IRQ Mode. Continuous S0 State Specify what state to go to when power is re- State After G3 S5 State applied after a power failure (G3 state). SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 71 Config PCH PCIe Lane 4~7 setting. Disabled The control of Active State Power DMI Link ASPM Control Management of the DMI Link. L0sL1 Auto PCI Express Root Port 0~7 <Sub Menu> PCI Express Root Port settings. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 72 Force L0s - Force all links to L0s State. ASPM AUTO - BIOS auto configure . L0sL1 DISABLE - Disables ASPM. Auto Disabled PCI Express Hot Plug Enable/Dis- Hot Plug Enabled able. Auto Gen1 PCIe Speed Configure PCIe Speed. Gen2 Gen3 SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 73 SATA And RST Configuration  SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 74 [0,1,2,3,5] DevSlp. For DevSlp to work, both hard drive and SATA SATA Port Disabled port need to support DevSlp func- [0,1,2,3,5] DevSlp Enabled tion, otherwise an unexpected behavior might occur. Please check board design before enabling it. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 75 HDD Unlock Enabled password unlock in the OS is enabled. If enabled, indicates that the LED/ Disabled LED Locate SGPIO hardware is attached and ping Enabled to locate feature is enabled on the OS. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 76 USB Configuration  Feature Options Description Option to enable Compliance Mode. Disabled Default is to disable Compliance Mode. XHCI Compliance Mode Enabled Change to enabled for Compliance Mode testing. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 77 Enable will lock bytes 38h-3Fh in the Disabled RTC Memory Lock lower/upper 128-byte bank of RTC Enabled RAM. Enable/Disable the PCH BIOS Lock Disabled BIOS Lock Enable feature. Required to be enabled Enabled to ensure SMM protection of flash. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 78 HD Audio Configuration  Feature Options Description Disabled HD Audio HD Audio Subsystem Configuration Settings. Enabled SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 79 This is needed to allow PCI enumerator access func- Disabled I2C0 Controller tions above 0 in a multifunction Enabled device. The following devices depend on each other: I2C0 and I2C1,2,3 UART0 and UART1,SPI0,1 UART2 and I2C4,5 SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 80 SCS Configuration  Feature Options Description Disabled Enable or Disable SCS SDHC 3.0 Con- SDCard 3.0 Controller Enabled troller. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 81 3.1.4 Security Select Security tab from the SOM-5899Refresh main BIOS setup menu. All security setup options, such as password protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>:...
  • Page 82 Note! Please keep your password safe. For security reasons, the BIOS pass- word can't be reset by clearing CMOS. If you forget your password, please contact Advantech for technical support. 3.1.4.1 Secure Boot Feature Options Description Disabled Secure Boot Set Administrator Password.
  • Page 83 Database (db). Device Guard ready system must not list 'Microsoft UEFI CA' Certifi- Remove 'UEFI CA' from DB cate in Authorized Signature data- base (db). Restore DB variable to factory Restore DB defaults defaults. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 84 One of Secure Boot variable. Append Delete Details Export Forbidden Signatures Update One of Secure Boot variable. Append Delete Update One of Secure Boot variable. Authorized TimeStamps Append Update Os Recovery Signatures One of Secure Boot variable. Append SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 85 OS and Post. If Auto, only install Legacy OpRom VGA Sup- Auto with Legacy OS and logo would NOT port (Note) EFI Driver be shown during post. Efi driver will still be installed with EFI OS. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 86 If Disabled, NetWork Stack Driver will Support Enabled be skipped. (Note) Redirection Disabled If disable, Redirection function will be Support Enabled disabled. (Note) Note! These items will be hidden when "Fast Boot" is disabled. 3.1.6 Save & Exit SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 87 Restore/Load Default values for all the Restore Defaults setup options. Save the changes done so far as User Save as User Defaults Defaults. Restore the User Defaults to all the Restore User Defaults setup options. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 88 SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 89 Chapter S/W Introduction & Installation  S/W Introduction  Driver Installation  Advantech iManager Arrow.com. Downloaded from...
  • Page 90 Embedded features easily integrate, speed up the development schedule, and pro- vide the customer’s with software continuity while upgrading hardware. For more details regarding how to use the APIs and utilities, please refer to the Advantech iManager 2.0 software API User Manual.
  • Page 91 SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 92 SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 93 Appendix Pin Assignment This appendix details the hard- ware pin assignment of the SOM- 5899Refresh CPU System on Mod- Sections include:  SOM-5899Refresh Type 6 Pin Assignment Arrow.com. Downloaded from...
  • Page 94 This section details SOM-5899Refresh pin assignment for the COM Express connec- tor, which is compatible with COM R.0 R3.0 Type 6 pin-out definitions. For further details on how to use these pins or for design reference, please contact Advantech for the design guide, checklist, reference schematic, and other hardware/software support.
  • Page 95 LVDS_A1+ LVDS_B1+ LVDS_A1- LVDS_B1- LVDS_A2+ LVDS_B2+ LVDS_A2- LVDS_B2- LVDS_VDD_EN LVDS_B3+ LVDS_A3+ LVDS_B3- LVDS_A3- LVDS_BKLT_EN GND (FIXED) GND (FIXED) LVDS_A_CK+ LVDS_B_CK+ LVDS_A_CK- LVDS_B_CK- LVDS_I2C_CK LVDS_BKLT_CTRL LVDS_I2C_DAT VCC_5V_SBY GPI3 VCC_5V_SBY N/A (Note 1) VCC_5V_SBY eDP_HPD VCC_5V_SBY SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 96 A107 VCC_12V B107 VCC_12V A108 VCC_12V B108 VCC_12V A109 VCC_12V B109 VCC_12V A110 GND (FIXED) B110 GND (FIXED) SOM-5899Refresh Row C,D GND (FIXED) GND (FIXED) USB_SSRX0- USB_SSTX0- USB_SSRX0+ USB_SSTX0+ USB_SSRX1- USB_SSTX1- USB_SSRX1+ USB_SSTX1+ USB_SSRX2- USB_SSTX2- USB_SSRX2+ USB_SSTX2+ GND (FIXED) GND (FIXED)
  • Page 97 PEG_TX1+ PEG_RX1- PEG_TX1- TYPE2# (GND) PEG_RX2+ PEG_TX2+ PEG_RX2- PEG_TX2- GND (FIXED) GND (FIXED) PEG_RX3+ PEG_TX3+ PEG_RX3- PEG_TX3- PEG_RX4+ PEG_TX4+ PEG_RX4- PEG_TX4- RAPID_SHUTDOWN PEG_RX5+ PEG_TX5+ PEG_RX5- PEG_TX5- GND (FIXED) GND (FIXED) PEG_RX6+ PEG_TX6+ PEG_RX6- PEG_TX6- SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 98 D102 PEG_TX15- C103 D103 C104 VCC_12V D104 VCC_12V C105 VCC_12V D105 VCC_12V C106 VCC_12V D106 VCC_12V C107 VCC_12V D107 VCC_12V C108 VCC_12V D108 VCC_12V C109 VCC_12V D109 VCC_12V C110 GND (FIXED) D110 GND (FIXED) SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 99 Appendix Watchdog Timer This appendix details information on the watchdog timer program- ming for the SOM-5899Refresh CPU System on Module Sections include:  Watchdog Timer Programming Arrow.com. Downloaded from...
  • Page 100 BIOS, and then sets to EC. Only Windows 8.1 and 10 support it. Other OS use the IRQ number from BIOS setting as usual. For details, please refer to the iManager and the Software API User Manual. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 101 Appendix Programming GPIO This Appendix illustrates the Gen- eral Purpose Input and Output pin settings. Sections include:  System I/O ports Arrow.com. Downloaded from...
  • Page 102 GPIO Byte Mapping H/W Pin Name BIT0 GPO0 BIT1 GPO1 BIT2 GPO2 BIT3 GPO3 BIT4 GPI0 BIT5 GPI1 BIT6 GPI2 BIT7 GPI3 For details, please refer to the iManager and Software API User Manual. SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 103 Appendix System Assignments This appendix details information about system resource allocation on the SOM-5899Refresh CPU System on Module Sections include:  System I/O ports  DMA Channel Assignments  Interrupt Assignments  1 MB Memory Map Arrow.com. Downloaded from...
  • Page 104 Programmable interrupt controller 00F0-00F0 Numeric data processor 0200-027F Motherboard resources 0280-028F Motherboard resources 0290-029F Motherboard resources 0299-029A Motherboard resources 029E-02AD Motherboard resources 02A0-02BF Motherboard resources 02C0-02DF Motherboard resources 02F0-02F7 Motherboard resources 02F8-02FF Communications port (COM2) SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 105 IRQ 0xFFFFFFFB (-5) Intel Management Engine Interface ® IRQ 0xFFFFFFFC(-4) Intel USB 3.1 eXtensible Host controller - 1.10 (Microsoft) ® IRQ 0xFFFFFFFD (-3) Intel UHD Graphics 630 IRQ 0xFFFFFFFE (-2) Standard SATA AHCI controller SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 106 0xFD6C0000- Motherboard resources 0xFD6CFFFF 0xFD6D0000- ® Intel Serial I/O GPIO Host controller - INT3450 0xFD6DFFFF 0xFD6E0000- ® Intel Serial I/O GPIO Host controller - INT3450 0xFD6EFFFF 0xFD6F0000- Motherboard resources 0xFDFFFFFF 0xFE000000- Motherboard resources 0xFE01FFFF SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 107 High precision event timer 0xFED003FF 0xFED10000- Motherboard resources 0xFED17FFF 0xFED18000- Motherboard resources 0xFED18FFF 0xFED19000- Motherboard resources 0xFED19FFF 0xFED20000- Motherboard resources 0xFED3FFFF 0xFED45000- Motherboard resources 0xFED8FFFF 0xFED90000- Motherboard resources 0xFED93FFF 0xFEE00000- Motherboard resources 0xFEEFFFFF 0xFF000000- Motherboard resources 0xFFFFFFFFF SOM-5899Refresh User Manual Arrow.com. Downloaded from...
  • Page 108 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2020 Arrow.com. Downloaded from...
