Altronix TROVE T2SSK1Q Installation Manual

Access & Power Integration
Altronix/Lenel-S2 (S2 Security Platform) Kits
Models Include:
T2SSK1Q
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with
TSS2 Altronix/Lenel-S2 (S2 Security Platform) backplane
- (1) eFlow104NB - Power Supply/Charger
- (1) eFlow102NB - Power Supply/Charger
- (1) LINQ8ACM - Networked Fused Access Power Controller
- (1) LINQ8PD - Networked Fused Power Distribution Module
- (1) NetWay5B - 5-Port Hardened Switch Board
- (1) RSB2 - Rocker Switch Bracket with Two (2) Rocker Switches
T2SSK2Q
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with
TSS2 Altronix/Lenel-S2 (S2 Security Platform) backplane
- (1) eFlow104NB - Power Supply/Charger
- (1) eFlow102NB - Power Supply/Charger
- (2) LINQ8ACM - Networked Fused Access Power Controllers
- (2) LINQ8PD - Networked Fused Power Distribution Modules
- (1) NetWay5B - 5-Port Hardened Switch Board
- (1) BR1 - Mounting Bracket
- (1) RSB2 - Rocker Switch Bracket with Two (2) Rocker Switches
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TSSK2Q_020524
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T2SSK1DQ
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with
TSS2 Altronix/Lenel-S2 (S2 Security Platform) backplane
- (1) eFlow104NB - Power Supply/Charger
- (1) eFlow102NB - Power Supply/Charger
- (1) LINQ8ACMCB - Networked PTC Access Power Controller
- (1) LINQ8PDCB - Networked PTC Power Distribution Module
- (1) NetWay5B - 5-Port Hardened Switch Board
- (1) RSB2 - Rocker Switch Bracket with Two (2) Rocker Switches
T2SSK2DQ
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with
TSS2 Altronix/Lenel-S2 (S2 Security Platform) backplane
- (1) eFlow104NB - Power Supply/Charger
- (1) eFlow102NB - Power Supply/Charger
- (2) LINQ8ACMCB - Networked PTC Access Power Controllers
- (2) LINQ8PDCB - Networked PTC Power Distribution Modules
- (1) NetWay5B - 5-Port Hardened Switch Board
- (1) BR1 - Mounting Bracket
- (1) RSB2 - Rocker Switch Bracket with Two (2) Rocker Switches
More than just power.™
