Access & Power Integration
Altronix/Software House Kits
Models Include:
T2SK78DV
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with
TSH2 Altronix/Software House backplane
- One (1) AL1024XB2V - Power Supply/Charger
- One (1) ACM8CB - PTC Protected Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input Power Distribution Module
- One (1) Rocker Switch Bracket with One (1) Rocker Switch
T3SK758DV
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove3 enclosure with
TSH3 Altronix/Software House backplane
- One (1) AL1024XB2V - Power Supply/Charger
- One (1) AL1012XB220 - Power Supply/Charger
- One (1) ACM8CB - PTC Protected Access Power Controller
- One (1) PD8ULCB - PTC Protected Power Distribution Module
- One (1) Rocker Switch Bracket with Two (2) Rocker Switches
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TSKLDV012623
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T3SK7516DV
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove3 enclosure with
TSH3 Altronix/Software House backplane
- One (1) AL1024XB2V - Power Supply/Charger
- One (1) AL1012XB220 - Power Supply/Charger
- Two (2) ACM8CB - PTC Protected Access Power Controllers
- One (1) PD8ULCB - PTC Protected Power Distribution Module
- One (1) Rocker Switch Bracket with Two (2) Rocker Switches
More than just power.™
Advertisement
Related Manuals for Altronix TROVE T2SK78DV
Summary of Contents for Altronix TROVE T2SK78DV
- Page 1 Fully assembled kit includes: Fully assembled kit includes: - Trove2 enclosure with - Trove3 enclosure with TSH2 Altronix/Software House backplane TSH3 Altronix/Software House backplane - One (1) AL1024XB2V - Power Supply/Charger - One (1) AL1024XB2V - Power Supply/Charger - One (1) ACM8CB - PTC Protected Access Power Controller...
-
Page 2: Configuration Chart
Overview: Altronix Trove Software House kits are pre-assembled and consist of Trove enclosure with factory installed Altronix power supply/chargers and sub-assemblies. These kits also accommodate various combinations of Software House boards for up to sixteen (16) doors in a single enclosure. - Page 3 COM (--- ) COM (--- ) PWR2 + PWR2 + Common Power Outputs (NEG) Altronix VR6 is mounted under PDS8CB Software House I8, R8 or I8-CSI Module Software House iSTAR Ultra ACM SE USB PORT USB Port Software House iStar Ultra ACM...
- Page 4 Note: Software House iSTAR Ultra ACM boards have one (1) USB port each. Please orient the board in the appropriate position according to the Fig. 3 below. 4. Fasten backplane to Trove3 enclosure utilizing lock nuts (provided). Fig. 3 Software House Altronix - AL1024ULXB2 Altronix AL1024XB2V iSTAR Ultra GCM AC DELAY RSB2...
- Page 5 Note: Software House iSTAR Ultra ACM boards have one (1) USB port each. Please orient the board in the appropriate position according to the Fig. 4 below. 4. Fasten backplane to Trove3 enclosure utilizing lock nuts (provided). Fig. 4 Software House Altronix - AL1024ULXB2 Altronix AL1024XB2V iSTAR Ultra GCM AC DELAY RSB2...
- Page 6 Notes: - 6 - Trove Software House XBV PTC Kits Installation Guide...
- Page 7 T2SK78D Enclosure Dimensions (H x W x D approximate): 27.25” x 21.5” x 6.5” (692.2mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77” 1.125” (28.3mm) (45mm) 2.415”...
- Page 8 8.75” (222.3mm) 2” (50.8mm) Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
