Modify An Existing Profile; Network Profile Tab; Figure 4-75 Modify Network Profile - LXE MX6 Reference Manual

158

Modify an Existing Profile

Access:
When you need to modify an existing profile, select the profile to be modified from the Preferred
Profiles List on the Config tab screen. Tap the Edit icon.
Set AP Search Threshold to Medium Density.
Note:

Network Profile tab

Name and Type
SSID
TX Rate
Type
Chan
MX6 Reference Guide
Start | Settings | Connections tab | 802.11b icon | Config tab

Figure 4-75 Modify Network Profile

The SSID, Type, TX Rate, and Channel fields are unchangeable in AP mode, whereas TX
Rate and Channel fields can be changed in Peer-to-Peer mode.
Enter an SSID, which is the Network Name. Check with your network
administrator for Network Name (SSID).
Choose 1Mb, 2 Mb, Auto 1/2 Mb, 5.5 Mb, 11 Mb, or Fully Auto from the menu.
The transmit rate is Fully Automatic by default.
Choose from Peer-to-Peer or Access Point in the pull down menu. Access Point
mode is also called "Infrastructure" mode. Peer-to-Peer mode is used for
communication between two (or more) radios (cards) without an access point.
Channel. Scroll to select a channel for communication.
Settings Options
E-EQ-MX6RG-E
