UG240: EFM8UB1-SLSTK2000A User's Guide
Kit Block Diagram
2. Kit Block Diagram
An overview of the EFM8UB1 Starter Kit is shown in the figure below.
Board
USB Micro-B
EFM8UB1
Controller
Connector
Microcontroller
Joystick
Figure 2.1. EFM8UB1-SLSTK2000A Block Diagram
silabs.com | Building a more connected world.
Rev. 0.4 | 3
