- Page 1 MOUNTING AND INSTRUCTION MANUAL TREND NTP NTP analog clock © MOBATIME BE-800912.06...
- Page 2 It is prohibited to reproduce, to store in a computer system or to transfer this publication in a way or another, even part of it. The copyright remains with all the rights with BÜRK MOBATIME GmbH, D-78026 VS-Schwenningen and MOSER-BAER AG – CH 3454 Sumiswald / SWITZERLAND.
-
Page 3: Table Of Contents
Redundant time source .......................... 13 6.9.1 NTP client unicast................................13 6.9.2 NTP client multicast ................................13 6.10 MOBA-NMS (MOBATime Network Management System) ..............14 7 Update ............................15 Bootloader update ..........................16 8 Time zone table ..........................17 9 Accessories ........................... 19 10 Technical data .......................... -
Page 4: Safety
Please observe the electromagnetic compatibility! This device complies with the requirements of the EMC and the Low-voltage Directive. Caution! © MOBATIME 4 / 20 800912.06... -
Page 5: Maintenance
Return your device to your supplier who will dispose of it correctly. Packaging Your device is packaged to protect it from damages during transport. Packaging is made of materials that can be disposed of in an environmentally friendly manner and properly recycled. © MOBATIME 5 / 20 800912.06... -
Page 6: General Information: Introduction
Automatic daylight saving time change according to a predefined rule. The rules can be programmed using the PC tool MOBA-NMS. Alternatively: daylight saving time change according to a rule of a MOBATime time zone server in the network. Integration into a monitoring system (SNMP-Manager) possible. The clocks can send SNMP V2 alarm notifications (traps) and periodical alive notifications. -
Page 7: Mounting Guidelines
Mounting guidelines Single-sided clock 4.1.1 Connections LAN - PoE push-button yellow LED: data activity green LED: connection 4.1.2 Mounting Ø 11 LAN connection (flex cable) with PoE © MOBATIME 7 / 20 800912.06... -
Page 8: Double-Sided Clock
Wall / ceiling set 10 cm Ceiling set 50 / 100 cm Bridge cable Art. no. 205132 Included in delivery Bridge cable Connection bridge cable brown movement brown MOBALine Notice: The cabling must correspond to the above drawing! © MOBATIME 8 / 20 800912.06... -
Page 9: Configuration
Time zone entry 7 Port number for configuration 65532 Port number for time zone client 65534 SNMP manager address 1 0.0.0.0 / 0::0 SNMP manager address 2 0.0.0.0 / 0::0 Interval SNMP Alive-Traps [min] (1…1440) © MOBATIME 9 / 20 800912.06... -
Page 10: Reset With Push-Button (Single-Sided Version Only)
The configuration can be carried out with MOBA-NMS. Further, this operating mode supports the monitoring of the clock through the network connection. Using MOBA- NMS, single configuration parameters can also be modified through the network connection. © MOBATIME 10 / 20 800912.06... - Page 11 NTP server on a fixed group address (multicast IP). The standard port numbers are 123 (NTP) and 65534 (time zone). The operating mode multicast means the least configuration effort for a network administrator. © MOBATIME 11 / 20 800912.06...
-
Page 12: Operating Behavior
In the unicast operating mode, the clock tries to obtain the network configuration from a DHCP server in the network. The DHCP options are evaluated automatically. The exact description can be found in the manual BE-800793 Description MOBATime network clocks. -
Page 13: Local Time Calculation
• sending interval secondary server: 1 package / 4 minutes The choice of server thus depends on the dominance of the server which sends out more NTP packages per time unit. Consequently, if the primary server falls out, the secondary server dominates. © MOBATIME 13 / 20 800912.06... -
Page 14: Moba-Nms (Mobatime Network Management System)
Further information, manuals and the software itself can be found on our website http://www.mobatime.com. If desired, it can also be sent out on a USB stick (must be ordered separately). -
Page 15: Update
Update…: Firmware update Bootloader update The newest versions of the firmware and bootloader are available at www.mobatime.com Customer Area Attention: Product Resources in the respective product folder. If the delivered device contains newer software than displayed in this manual, please check the settings. -
Page 16: Bootloader Update
A bootloader update is only necessary if the respective alarm is displayed: In case of a bootloader alarm, the selection field for the firmware (application) is deactivated and only made available after a successful bootloader update: Important: The bootloader file must be a .zip file. © MOBATIME 16 / 20 800912.06... -
Page 17: Time Zone Table
South Australia: Adelaide +9.5 Sun. Oct (02:00) Sun. Apr. (03:00) Northern Territory: Darwin +9.5 Brisbane, Guam, Port Moresby, Magadan, Vladivostok Sydney, Canberra, Sun. Oct. (02.00) Sun. Apr. (03:00) Melbourne, Tasmania: Hobart UTC (GMT) UTC (GMT) © MOBATIME 17 / 20 800912.06... - Page 18 Switch over on the penultimate Sunday in March at 02.00 hours local time. Notice: As usual, the time table is adapted each year. You can download the newest time table from our homepage: www.mobatime.com Downloads Moba-Software Time Zone Table. If the delivered device contains a newer version as showed in this manual, it’s recommended to check the...
-
Page 19: Accessories
Calculation of local time automatic daylight saving time change, selectable from 7 predefined and daylight saving time rules or change daylight saving time change from external MOBATime time zone server, selectable from 7 entries Accuracy deviation typically <+/-50 ms in synchronized state hands on 12 o’clock position after 24 h... - Page 20 © MOBATIME BE-800912.06...
