LINK INSTALLATION MANUAL LK-EXL11R Ford Explorer 2011-2015 Front Right...
Page 2
Air Bag LINK Kit -Right- LK-EXL11-BK Bolt Kit EW-CK-00 12V Power Supply Wiring Kit LK-UNI-650 Manual Backup Tool Kit TO INSTALL IF VENTILETED SEAT OPTION PART NUMBER LK-EXL11R DESCRIPTION LINK Ford Explorer 2011 & Up -Right- 1 of 4 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
Page 3
Wave Disc Spring 0.325 id x 0.546 od x 0.007 thickness PRD 337-210P Button head socket cap screw Zinc Plated 5/16-18 x 3/8 PART NUMBER LK-EXL11R DESCRIPTION LINK Ford Explorer 2011 & Up -Right- 2 of 4 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
Page 4
Round washer head tapping screw #8 x 3/4 PRD 333-107 Nylon Insert Locknut 5/16-18 PRD 339-136P Socket Shoulder Screw Zinc Plated 3/8 x 1/2 x 5/16-18 THD PART NUMBER LK-EXL11R DESCRIPTION LINK Ford Explorer 2011 & Up -Right- 3 of 4 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
Page 5
Flat Washer Zinc Plated I.D. 3/8 USS PRD 342-115P Spring Lockwasher Zinc plated 5/16 PRD 20234P Hex cap bolt zinc plated M10-1,5 x 40mm G8.8 PART NUMBER LK-EXL11R DESCRIPTION LINK Ford Explorer 2011 & Up -Right- 4 de 4 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
Page 6
Take a moment and watch the video that shows all the features of the tablet. To do this, open the LINK IT app and tap on ‘INFO’. Make sure your volume is turned up and tap on App-101.
Page 7
1. Remove the OEM seat buy unbolting the seat brackets and disconnecting the seat wiring harness. 2. The driver side seat will also have to be removed to enable the modification of the front seat rear cross member. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 3...
Page 8
3. The front seat rear cross member will have to be removed to be cut and modified. This entails removing the doorsill, b-pillar plastic trims, and seat belt on the two sides and raising the rear of the center console. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 4...
Page 9
LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 5...
Page 10
4. Once the center console is lifted, the cross member can then be removed and cut in the middle and then the left-hand side seat cross member can be reinstalled. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 6...
Page 11
5. The LINK floor adapters can now be installed. First install the two front floor shims # LK-EXL11R-06 interior and # LK-EXL11R-07 exterior, then install the exterior floor adapter # LK-EXL11R-01 using the two M10X1.5X40mm bolts at the front and two M10x1.5x40mm bolts at the back. The seat belt cannon will also be reinstalled at this point using the OEM bolt.
Page 12
Now tighten down the bolts on the exterior floor adapter. 7. Run the power from the battery to the LINK. To do this, thread the red power cable (+) under the doorstep moulding and through the firewall. Make sure you pass through a grommet in the firewall to prevent the cable from chaffing.
Page 13
8. The b pillar shroud can now be modified with the provided stencils to allow the LINK to pass and then reinstalled. Then the seat belt can be reinstalled, and also the provided plastic covers. 9. Remove the LINK from the shipping box and set it on a table or workbench. Connect auxiliary 12V power to the LINK.
Page 14
(8) bolt holes. 11. Place the LINK in the vehicle on the floor adapter. Use the four (4) 3/8’’-16 x 1¼’’ socket cap bolts to secure the LINK by the pivot, and use the four (4) 3/8’’-16 x 7/8’’ to secure the interior of the LINK. Be careful not to pinch the LINK wire harness between the LINK and the floor adapter.
Page 15
13. The center console and left hand seat can now be reinstalled. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 11...
Page 16
14. The original OEM seat and seat wiring will have to be modified for installation on the LINK. Start by installing the seat on a workbench and remove the plastic seat trims, and electric seat controls LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 12...
Page 17
15. Remove the seat base wiring harness. 16. Remove the seat back. To do so the remove the lumbar adjustment cable. 17. Remove the seat belt receiver. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 13...
Page 18
18. Remove the seat cushion from the frame. 19. Remove the occupant sensor pad and module. The seat pan and seat cushion support can now be removed from the seat frame. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 14...
Page 19
20. Remove the lumbar adjuster and seat trim support. NOTE: the manual lumbar adjuster will have to be drilled out as it is riveted to the seat base. 21. Remove the seat position sensor. Reconnect the position sensor to the harness. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 15...
Page 20
(If you wish to keep a record of your wire extensions for reference, you will find a lined sheet at the very end of this manual for that purpose.) LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 16...
Page 21
Note: the wiring when reinstalled will run out of the bottom right hand corner of the seat and go back under the LINK to be reconnected to the floor connector with enough loose to be able to follow the seat in and out.
Page 22
Reinstall the manual lumbar control onto the LINK seat adapter using the provided self tapping screws. 24. Reinstall the metal seat pan using the six, self tapping screws provided. 25. Install the seat trim support onto the seat adapter. 26. Reinstall the seat cushion supports.
Page 23
27. Connect the previously installed 12v power supply to the LINK, and using the ‘BYPASS’ mode on your ADAPT SOLUTIONS tablet carefully ‘pivot’ ‘travel’ and ‘tilt’ the LINK out of the vehicle to install the seat. MODELS WITH SEAT COOLING Follow steps 28 to 35 28.
Page 24
Once they are in place crimp them using a crimping tool or a hammer and blunt chisel. 30. Reinstall the supports to the fan. Unclip the fan connector to be able to install the connector side. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 20...
Page 25
32. The seat cushion will have to be modified before re-installation. The first modification is to allow clearance for the modified fan. The second is to the fabric flap to allow clearance under the LINK. For the fan modification, measure five inches towards the back of the seat to find the center and then mark a square four x four inches.
Page 26
35. Re-install the seat adapter to the LINK, be sure to re install the control box wire support. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 22...
Page 27
37. Reinstall the seat occupant sensor pad and module. To facilitate the installation of the sensor, use the tablet in ‘BYPASS’ mode ‘tilt’ to tilt the LINK up. Locate the module at the side of the seat adapter and attach securely with zip ties.
Page 28
38. The seat cushion will have to be modified before installation by removing the plastic trim and then reinstalled attaching the fabric flap under the seat with zip ties. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 24...
Page 29
40. Reinstall the seat back, at the same time run the extended wiring into the lower right hand corner of the seat place the connectors in the locations where they will be reconnected. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 25...
Page 30
43. Close up the back of the seat then ‘tilt’ the seat up with your ADAPT SOLUTIONS tablet to attach the fabric flap of the seat back with zip ties underneath the seat cushion. Then reconnect the seat occupant sensor. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 26...
Page 31
Bluetooth module. The connector can be attached with velcro under the shroud. Verify the positioning of the wire to make sure there is no chance of it pinching or binding once the seat moves. LINK RIGHT 2011-2015 FORD EXPLORER FRONT RIGHT p. 27...
Page 32
Attach the extended wiring temporarily at the back of the seat. Bring the LINK out to verify if you have enough wire to follow the LINK in and out. Attach the wire at the back of the seat and at the lower corner of the LINK. Roll up any excess wiring on the floor under the LINK.
Page 33
If the LINK is slightly off its ‘HOME’ position or the starting point of its movements, there is a strong chance that the LINK will not fit through the doorway properly and/or will cause problems with the preset of the LINK.
Page 34
Bluetooth module and plug in the hand pendant. Make sure the LINK hand pendant is working properly. Cycle the LINK in and out a few times, both with and without a passenger to make sure all shrouds are properly installed and that nothing is rubbing or requires adjustment. Make a visual inspection while the LINK is in movement that all the wiring follows the seat and does not risk being severed at any time.
Page 35
9 vo lt b a tte ry is stro ng ly sug g e ste d . T he LINK 's me mo ry b a c k up b a tte ry (9 vo lt) is lo w o r d e a d .
