- Page 1 LINK INSTALLATION MANUAL LK-F150C09L FORD F150 CREW CAB, SUPER CAB 2009-2014 FRONT LEFT...
- Page 2 LINK Wired Control LK-F150C09L-AB Air Bag LINK Kit -Left- EW-CK-00 12V Power Supply Wiring Kit LK-UNI-650 Manual Backup Tool Kit PART NUMBER LK-F150C09L DESCRIPTION 1 of 4 LINK Ford F-150 Supercrew Cab 2009 - 2014 -Left- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 3 Trhead: 1/4 - 20 UNC Drill: 5/16" Step 1: Drill Ø5/16 (2 thickness) Step 2: Drill: 3/16" Step 3: Thread 1/4 - 20 UNC PART NUMBER LK-F150C09L DESCRIPTION 2 of 4 LINK Ford F-150 Supercrew Cab 2009 - 2014 -Left- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 4 Trim Panel Clip Ø1/4'' x 3/4'' Black PRD 333-107 Nylon Insert Locknut 5/16-18 PRD 339-136P Socket Shoulder Screw Zinc Plated 3/8 x 1/2 x 5/16-18 THD PART NUMBER LK-F150C09L DESCRIPTION 3 of 4 LINK Ford F-150 Supercrew Cab 2009 - 2014 -Left- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 5 Socket Head Cap Screw Zinc Plated 3/8-16 x 7/8 PRD 332-166P Socket Head Cap Screw Zinc Plated 3/8-16 x 1 1/4 PRD 342-115P Spring Lockwasher Zinc plated 5/16 PART NUMBER LK-F150C09L DESCRIPTION LINK Ford F-150 Supercrew Cab 2009 - 2014 -Left- 4 of 4 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 6 REFERENCES LINK L K- F150C 09L *Transfer height: 19”| INFO N/ A Se a t he ig ht: A ve ra g e insta ll: 8- 10 hrs (Ra p to r 10- 12 hrs) O EM shro ud s must b e trim me d .
- Page 7 Take a moment and watch the video that shows all the features of the tablet. To do this, open the LINK IT app and tap on ‘INFO’. Make sure your volume is turned up and tap on App-101.
- Page 8 Make sure the steering wheel adjustment is fully UP and IN to allow maximum clearance for the driver seat. When installing the LINK with hand controls, hand controls should be installed after the LINK. 1. Unbolt and remove the OEM seat. Unplug the connectors under the seat.
- Page 9 3. Remove the seat frame. To do so you will have to unplug components of the seat electrical harness and then remove the seat wiring harness. 4. Remove the air bag seat position sensor and reconnect to the wiring. p. 4 LINK 2009-2014 FORD F150 CREW CAB/ SUPERCAB/ FRONT LEFT...
- Page 10 The control box module and seat position sensor are relocated onto the floor. The wiring extension will be routed out of the bottom left hand corner of the seat. p. 5 LINK 2009-2014 FORD F150 CREW CAB/ SUPERCAB/ FRONT LEFT...
- Page 11 6 LINK 2009-2014 FORD F150 CREW CAB/ SUPERCAB/ FRONT LEFT...
- Page 12 6. Reinstall the wiring into the seat, run the extension out of the bottom left hand corner of the seat. Attach the wires securely with zip ties. 7. The seat height adjustment motor will have to be removed. Install the supplied bracket, part #LK- F150C09L-04 in its place. p. 7 LINK 2009-2014 FORD F150 CREW CAB/ SUPERCAB/ FRONT LEFT...
- Page 13 Run the power from the battery to the LINK. To do this, thread the red power cable (+) under the doorstep moulding and through the firewall. Make sure you pass through a grommet in the firewall to prevent the cable from chaffing.
- Page 14 (8) bolt holes. 12. Place the LINK in the vehicle on the floor adapter. Use the four longer (3/8’’-16 x 1¼’’) socket cap bolts to secure the LINK by the pivot, and use the four shorter (3/8’’-16 x 7/8’’) to secure the interior of the LINK.
- Page 15 13. Connect the previously installed 12V power supply to the LINK. Using the LINK IT application, use ‘BYPASS’ mode to ‘TILT’ the seat adapter up to facilitate the installation of the seat onto the LINK. 14. Reconnect the extended harness. Install the provided plastic cover.
- Page 16 Verify the positioning of the wire to make sure there is no chance of it pinching or binding once the seat moves. 16. The left hand seat trim will have to be modified to allow clearance for the LINK. Modify the seat shroud to fit around the pivot block, as shown. Reinstall the plastic seat trim and electric seat controls.
- Page 17 If the LINK is slightly off its ‘HOME’ position or the starting point of its movements, there is a strong chance that the LINK will not fit through the doorway properly and/or will cause problems with the preset of the LINK.
- Page 18 Now that the LINK is in its ‘HOME’ position, RESET the unit by pressing ‘CONFIRM RESET’. A screen will pop up to ask: ‘ARE YOU SURE YOU WANT TO RESET?’. Press ‘ACCEPT’. The LINK will emit two (2) audible beeps to confirm ‘RESET’, and will now be in reduced power mode.
-
Page 19: Audibl E Warning S
9 vo lt b a tte ry is stro ng ly sug g e ste d . T he LINK 's me mo ry b a c k up b a tte ry (9 vo lt) is lo w o r d e a d . -
Page 20: Normal Use
All systems functional and ready to go. Power Reduce Mode To exit, simply run the LINK a full cycle. Major Problem Do not use the LINK - contact your Mobility Equipment Dealer No Response No 12V Power DIAG NO ST IC MO DE... -
