APPENDIX A

TAWS ALERTS

Annunciations appear on the PFD and MFD. Pop-up alerts appear only on the MFD.
Alert Type
Excessive Descent Rate
Warning (EDR)
Reduced Required Terrain
Clearance Warning (RTC)
Imminent Terrain Impact
Warning (ITI)
Reduced Required Obstacle
Clearance Warning (ROC)
Imminent Obstacle Impact
Warning (IOI)
Reduced Required Terrain
Clearance Caution (RTC)
Imminent Terrain Impact
Caution (ITI)
Reduced Required Obstacle
Clearance Caution (ROC)
Imminent Obstacle Impact
Caution (IOI)
Premature Descent Alert
Caution (PDA)
Altitude Callout "500"
Excessive Descent Rate
Caution (EDR)
Negative Climb Rate Caution
(NCR)

TAWS SYSTEM STATUS ANNUNCIATIONS

Alert Type
TAWS System Test Fail
TAWS Alerting is disabled
No GPS position or excessively
degraded GPS signal
System Test in progress
System Test pass
A-18
PFD/MFD
MFD Map Page
TAWS Page
Pop-Up Alert
Annunciation
None None
PFD/MFD
TAWS Page
Pop-Up Alert
Annunciation
None
Garmin G1000 Pilot's Guide for the Quest Kodiak 100
"Terrain, Terrain; Pull Up, Pull Up"
"Terrain, Terrain; Pull Up, Pull Up"
"Obstacle, Obstacle; Pull Up, Pull Up"
"Obstacle, Obstacle; Pull Up, Pull Up"
"Caution, Terrain; Caution, Terrain"
"Caution, Terrain; Caution, Terrain"
"Caution, Obstacle; Caution, Obstacle"
"Caution, Obstacle; Caution, Obstacle"
"Too Low, Terrain"
MFD
None "TAWS System Failure"
None
None "TAWS Not Available"
"TAWS Available" will be heard when sufficient
GPS signal is re-established.
None
None "TAWS System Test OK"
Aural Message
"Pull Up"
"Five-Hundred"
"Sink Rate"
"Don't Sink"
Aural Message
None
None
