External Appearance - intensity VRF V5 Series Service Manual

V5 X VRF 460V 60Hz

2 External Appearance

2.1 Indoor Units
2.1.1 Standard indoor units
Table 1-2.1: Standard indoor unit appearance
One-way Cassette
Q1
Compact Four-way Cassette
Q4C
Medium Static Pressure Duct
T2
Wall-mounted
G
Floor Standing
F
2.1.2 Fresh air processing unit
Table 1-2.2: Fresh air processing unit appearance
Fresh Air Processing Unit
FA
2.2 Heat Recovery Ventilator
Table 1-2.3: Heat recovery ventilator appearance
Heat Recovery Ventilator
6
Two-way Cassette
Q2
Four-way Cassette
Q4
High Static Pressure Duct
T1
Ceiling & Floor
DL
Console
Z
