intensity VRF V5 Series Service Manual page 103

Table 5-5.3: Inverter module temperature sensor resistance characteristics
Temperature
Resistance
(kΩ)
(°C)
971.4
-30
912.8
-29
858.2
-28
807.3
-27
759.7
-26
715.3
-25
673.6
-24
634.7
-23
598.2
-22
564.1
-21
532.2
-20
502.2
-19
474.1
-18
447.7
-17
423.0
-16
399.8
-15
378.0
-14
357.5
-13
338.2
-12
320.1
-11
303.1
-10
287.1
-9
272.0
-8
257.8
-7
244.4
-6
231.9
-5
220.0
-4
208.7
-3
198.2
-2
188.2
-1
178.8
0
169.9
1
161.5
2
153.6
3
146.1
4
139.1
5
132.3
6
126.0
7
120.0
8
114.3
9
Temperature
Resistance
(kΩ)
(°C)
109.0
10
103.9
11
99.02
12
94.44
13
90.11
14
86.00
15
82.09
16
78.38
17
74.87
18
71.53
19
68.36
20
65.34
21
62.47
22
59.75
23
57.17
24
54.71
25
52.36
26
50.13
27
48.01
28
45.99
29
44.07
30
42.23
31
40.48
32
38.81
33
37.23
34
35.71
35
34.27
36
32.89
37
31.58
38
30.33
39
29.13
40
27.98
41
26.89
42
25.85
43
24.85
44
23.90
45
22.98
46
22.10
47
21.26
48
20.47
49
Temperature
Resistance
(kΩ)
(°C)
19.70
50
18.97
51
18.26
52
17.59
53
16.94
54
16.32
55
15.73
56
15.16
57
14.62
58
14.10
59
13.60
60
13.12
61
12.65
62
12.22
63
11.79
64
11.39
65
10.99
66
10.62
67
10.25
68
9.909
69
9.576
70
9.253
71
8.947
72
8.646
73
8.362
74
8.089
75
7.821
76
7.569
77
7.323
78
7.088
79
6.858
80
6.640
81
6.432
82
6.230
83
6.033
84
5.847
85
5.667
86
5.492
87
5.322
88
5.159
89
V5 X VRF 460V 60Hz
Temperature
Resistance
(kΩ)
(°C)
5.000
90
4.855
91
4.705
92
4.566
93
4.431
94
4.301
95
4.176
96
4.055
97
3.938
98
3.825
99
3.716
100
3.613
101
3.514
102
3.418
103
3.326
104
3.235
105
3.148
106
3.063
107
2.982
108
2.902
109
2.826
110
2.747
111
2.672
112
2.599
113
2.528
114
2.460
115
2.390
116
2.322
117
2.256
118
2.193
119
2.132
120
2.073
121
2.017
122
1.962
123
1.910
124
1.859
125
