Table 4-1.1: Outdoor unit main PCB switch settings (continued)
Switch Setting
Priority mode
S5
Addressing
mode 4
S6
Number of
indoor units
S7
manually set
S8/S10
ENC3 S12
Number of
indoor units
Outdoor unit
address
ENC1
Outdoor unit
capacity
5
ENC2
Network
address
ENC4
Notes:
1. Black denotes the switch position.
3. Refer to Part 4, 1.2.2 "Priority mode setting".
4. Refer to Part 4, 1.2.3 "Addressing mode setting".
5.
Switch ENC2 is factory-set and its setting should not be changed.
Switch positions 1
S5
ON Heating priority (default)
1 2 3
S5
ON Cooling priority
1 2 3
S5
ON VIP priority or voting priority
3
1 2 3
Heating only
S5
ON Cooling only
1 2 3
Auto addressing
S6
ON
Manual addressing (default)
1 2 3
Clear indoor unit addresses
The number of indoor units is not manually set (default)
The number of indoor units is manually set on switches ENC3 and S12
S12
The number of indoor units is in the range 0-15
ENC3
ON
0-9 on ENC3 indicate 0-9 indoor units; A-F on ENC3 indicate 10-15 indoor units
1 2
S12
The number of indoor units is in the range 16-31
ENC3
ON
0-9 on ENC3 indicate 16-25 indoor units; A-F on ENC3 indicate 26-31 indoor units
1 2
S12
The number of indoor units is in the range 32-47
ENC3
ON
0-9 on ENC3 indicate 32-41 indoor units; A-F on ENC3 indicate 42-47 indoor units
1 2
S12
The number of indoor units is in the range 48-63
ENC3
ON
0-9 on ENC3 indicate 48-57 indoor units; A-F on ENC3 indicate 58-63 indoor units
1 2
Only 0, 1, 2, 3 should be selected
0 is for master unit; 1, 2, 3 are for slave units
Only 0, 1, 2, 3, 4, 5, 6, 7 should be selected
0: 8HP; 1: 10HP; 2: 12HP; 3: 14HP; 4: 16HP; 5: 18HP; 6: 20HP; 7: 22HP
Only 0, 1, 2, 3, 4, 5, 6, 7 should be selected
Description
Reserved
