intensity VRF V5 Series Service Manual page 101

5 Appendix to Part 5
5.1 Temperature Sensor Resistance Characteristics
Table 5-5.1: Outdoor ambient temperature sensor and outdoor heat exchanger temperature sensor resistance characteristics
Temperature Resistance
(°C) (kΩ)
115.3
-20
108.1
-19
101.5
-18
96.34
-17
89.59
-16
84.22
-15
79.31
-14
74.54
-13
70.17
-12
66.09
-11
62.28
-10
58.71
-9
56.37
-8
52.24
-7
49.32
-6
46.57
-5
44.00
-4
41.59
-3
39.82
-2
37.20
-1
35.20
0
33.33
1
31.56
2
29.91
3
28.35
4
26.88
5
25.50
6
24.19
7
22.57
8
21.81
9
20.72
10
19.69
11
18.72
12
17.80
13
16.93
14
16.12
15
15.34
16
14.62
17
13.92
18
13.26
19
Temperature Resistance
(°C) (kΩ)
12.64
20
12.06
21
11.50
22
10.97
23
10.47
24
10.00
25
9.551
26
9.124
27
8.720
28
8.336
29
7.971
30
7.624
31
7.295
32
6.981
33
6.684
34
6.400
35
6.131
36
5.874
37
5.630
38
5.397
39
5.175
40
4.964
41
4.763
42
4.571
43
4.387
44
4.213
45
4.046
46
3.887
47
3.735
48
3.590
49
3.451
50
3.318
51
3.192
52
3.071
53
2.959
54
2.844
55
2.738
56
2.637
57
2.540
58
2.447
59
Temperature Resistance
(°C) (kΩ)
2.358
60
2.272
61
2.191
62
2.112
63
2.037
64
1.965
65
1.896
66
1.830
67
1.766
68
1.705
69
1.647
70
1.591
71
1.537
72
1.485
73
1.435
74
1.387
75
1.341
76
1.291
77
1.254
78
1.2133
79
1.174
80
1.136
81
1.100
82
1.064
83
1.031
84
0.9982
85
0.9668
86
0.9366
87
0.9075
88
0.8795
89
0.8525
90
0.8264
91
0.8013
92
0.7771
93
0.7537
94
0.7312
95
0.7094
96
0.6884
97
0.6682
98
0.6486
99
V5 X VRF 460V 60Hz
Temperature Resistance
(°C) (kΩ)
0.6297
100
0.6115
101
0.5939
102
0.5768
103
0.5604
104
0.5445
105
0.5291
106
0.5143
107
0.4999
108
0.4860
109
0.4726
110
0.4596
111
0.4470
112
0.4348
113
0.4230
114
0.4116
115
0.4006
116
0.3899
117
0.3796
118
0.3695
119
0.3598
120
0.3504
121
0.3413
122
0.3325
123
0.3239
124
0.3156
125
0.3075
126
0.2997
127
0.2922
128
0.2848
129
0.2777
130
0.2708
131
0.2641
132
0.2576
133
0.2513
134
0.2451
135
0.2392
136
0.2334
137
0.2278
138
0.2223
139
