intensity VRF V5 Series Service Manual page 102

V5 X VRF 460V 60Hz
Table 5-5.2: Compressor top temperature sensor and discharge pipe temperature sensor resistance characteristics
Temperature
Resistance
(kΩ)
(°C)
542.7
-20
511.9
-19
483.0
-18
455.9
-17
430.5
-16
406.7
-15
384.3
-14
363.3
-13
343.6
-12
325.1
-11
307.7
-10
291.3
-9
275.9
-8
261.4
-7
247.8
-6
234.9
-5
222.8
-4
211.4
-3
200.7
-2
190.5
-1
180.9
0
171.9
1
163.3
2
155.2
3
147.6
4
140.4
5
133.5
6
127.1
7
121.0
8
115.2
9
109.8
10
104.6
11
99.69
12
95.05
13
90.66
14
86.49
15
82.54
16
78.79
17
75.24
18
71.86
19
100
Temperature
Resistance
(kΩ)
(°C)
68.66
20
65.62
21
62.73
22
59.98
23
57.37
24
54.89
25
52.53
26
50.28
27
48.14
28
46.11
29
44.17
30
42.33
31
40.57
32
38.89
33
37.30
34
35.78
35
34.32
36
32.94
37
31.62
38
30.36
39
29.15
40
28.00
41
26.90
42
25.86
43
24.85
44
23.89
45
22.89
46
22.10
47
21.26
48
20.46
49
19.69
50
18.96
51
18.26
52
17.58
53
16.94
54
16.32
55
15.73
56
15.16
57
14.62
58
14.09
59
Temperature
Resistance
(kΩ)
(°C)
13.59
60
13.11
61
12.65
62
12.21
63
11.79
64
11.38
65
10.99
66
10.61
67
10.25
68
9.902
69
9.569
70
9.248
71
8.940
72
8.643
73
8.358
74
8.084
75
7.820
76
7.566
77
7.321
78
7.086
79
6.859
80
6.641
81
6.430
82
6.228
83
6.033
84
5.844
85
5.663
86
5.488
87
5.320
88
5.157
89
5.000
90
4.849
91
4.703
92
4.562
93
4.426
94
4.294
95
4.167
96
4.045
97
3.927
98
3.812
99
Temperature
Resistance
(kΩ)
(°C)
3.702
100
3.595
101
3.492
102
3.392
103
3.296
104
3.203
105
3.113
106
3.025
107
2.941
108
2.860
109
2.781
110
2.704
111
2.630
112
2.559
113
2.489
114
2.422
115
2.357
116
2.294
117
2.233
118
2.174
119
2.117
120
2.061
121
2.007
122
1.955
123
1.905
124
1.856
125
1.808
126
1.762
127
1.717
128
1.674
129
1.632
130
