Installing the TIM 3V-IE variants in an S7-300
Introduction
The TIM 3V-IE variants can be used in an S7-300 as communications processors (CP). In
principle, all S7-300 standard and compact CPUs can be combined with these TIMs. There
are, however, constraints that must be taken into account relating to the way in which data
exchange between the TIM and the CPU in the rack is handled (the SINAUT program). For
the TIM 3V-IE variants, there are two options:
1. TD7onTIM
2. TD7onCPU
The following CPU lists also include older CPU types that can no longer be ordered as new
devices but that nevertheless may still be in use in the field. These are shown in
parentheses.
Standard CPU modules
CPU 312
(CPU 312 IFM)
(CPU 313)
CPU 314
(CPU 314 IFM)
(CPU 315)
CPU 315-2 DP
CPU 315-2 PN/DP
CPU 315T-2 DP
CPU 315F-2 DP
CPU 315F-2 PN/DP
(CPU 316)
(CPU 316-2 DP)
CPU 317-2 DP
CPU 317-2 PN/DP
CPU 317T-2 DP
CPU 317F-2 DP
SINAUT ST7 Station control system - System Manual
System Manual, 05/2007, C79000-G8976-C178-06
This SINAUT TD7 program runs on the TIM.
All standard and compact CPUs can be used with restriction.
This SINAUT TD7 program runs on the CPU and is created for the CPU with blocks from
the SINAUT TD7 library.
In this case, only CPUs with a work memory adequate to accommodate the SINAUT
program can be used. The size of the program depends on the amount of data to be
transmitted. At least 20 Kbytes are required. TD7onCPU can be used for several
standard CPU types if the following software packages are used:
– "SINAUT TD7 library for the CPU" as of V2.2
– "TIM firmware" as of V1.2
You will find the CPUs affected in the list below.
as of 6ES7 312-1AD10-0AB0
as of 6ES7 312-5AC00-0AB0
as of 6ES7 313-1AD00-0AB0
as of 6ES7 314-1AE02-0AB0
as of 6ES7 314-5AE02-0AB0
as of 6ES7 315-1AF01-0AB0
as of 6ES7 315-2AF01-0AB0
as of 6ES7 315-2EG10-0AB0 *
as of 6ES7 315-6TG10-0AB0
as of 6ES7 315-6FF00-0AB0
as of 6ES7 315-2FH10-0AB0 *
as of 6ES7 316-1AG00-0AB0
as of 6ES7 316-2AG00-0AB0
as of 6ES7 317-2AJ10-0AB0 *
as of 6ES7 317-2EJ10-0AB0 *
as of 6ES7 317-6TJ10-0AB0 *
as of 6ES7 317-6FF00-0AB0 *
3.4 Installing the TIM 3V-IE variants in an S7-300
)
)
)
)
)
)
Installation guide
119
