NTI INFRARED MOTION DETECTOR
FEATURES
#
ITEM
DESCRIPTION
1
Sensor
Infrared Motion Sensor
Switch
Tamper switch - NC
2
Jumper blocks
For placement of delay jumper
3
LED
Illuminates Red to indicate when motion is sensed
4
5
Wire Terminal Block
For connection of ENVIROMUX and power wires
6
Hole in Case
Pre-drilled hole for passage of wires into case
