H-1595
mini towel dispenser

tools needed

drill
dispenser x 1

using the key and optional push button mode

usInG tHE kEy
1. to open dispenser while keeping it locked, insert key
at position A. (see Figure 1)
2. turn and hold key clockwise to open dispenser.
(see Figure 2)
note: Release key back to position a after
closing to lock dispenser.
PAGE 1 OF 2
1-800-295-5510
uline.com
6mm drill bit
Phillips screwdriver
dispenser key x 1
Figure 1
Figure 2

paRts list

Wall Anchor x 4
usInG PusH buttOn mOdE
1.
Insert key at position A. (see Figure 1)
2. turn counterclockwise to position b. (see Figure 3)
3. Remove key and push in lock to open dispenser.
(see Figure 4)
screw x 4
Figure 3
Figure 4
0214 IH-1595
