- Page 1 MP-878 Series Mini-PCI Video Capture Card User’s Manual Edition Release Date 2007/01/25 2008/06/10...
- Page 2 Trademark All trademarks are the property of their respective holders. Any questions please visit our website at h ttp://www.commell.com.tw...
- Page 3 Packing List: Please check the package content before you starting using the board. Hardware: ◆ 1 x MP-878 series Mini-PCI Video Capture card ◆ 1 x Cable support S-video & Composite for MP-878D ◆ 2 x Cable support S-video & Composite for MP-878D2 ◆...
-
Page 4: Table Of Contents
MP-878D User’s Manual Index Chapter 1 <Introduction> 1.1 <Product Overview>................6 1.2 <Hardware requirement>…………………………………………………6 1.3 <Software requirement>…………………………………………………..6 1.4 < Dimensions> …………………………………………………………….7 1.5 < Hardware installation> …………………………………………………8 1.6< Software installation> …………………………..……………………….9 1.7< Sample program> ……………………………………………………..20 Contact Information ..................233... - Page 5 MP-878D User’s Manual (This Page is left for Blank)
-
Page 6: Chapter 1
Chapter 1 <Introduction> 1.1 <Product Overview> COMMELL MP-878 series is a Video input Video Capture Card . That Support up to D1 resolution at 30/25 fps (one Chip). Also MP-878 series supports NTSC/PAL signals. (MP-878D2/D8 is allow 2 Cards which installed in one PC system. If user wants to use... -
Page 7: Dimensions
MP-878D User’s Manual 1.4<Dimensions> 44.6 x 59.5 mm ( Mini-PCI Type-III B ) Figure 1.2... -
Page 8: Hardware Installation
3. Touch the metal part on the surface of your computer to neutralize Any static electricity that might be on your body. 915GM 4. Place the MP-878 series into the Motherboard’s Mini-PCI slot and connect Corresponding accessories to the MP-878 series. 5. Replace the cover of your computer chassis 6. -
Page 9: Software Installation
MP-878D User’s Manual 1.6<Software installation > When you completed the Hardware installation, the system will auto –detect And a message pops up as following: Please all select “ Cancel “... - Page 10 MP-878D User’s Manual Then, Insert the driver CD into your system’s CD-ROM to Set up MP-878 series. Run Setup.exe (E:/Media/SINGLE.EXE_IMAGE/Disk Image/Disk/Setup.exe) Please select “ Next “ to continue.
- Page 11 MP-878D User’s Manual Please read the following License Agreement. Press the Page Down key to see the rest of agreement and click “ Yes “ to continue the installation.
- Page 12 MP-878D User’s Manual Please fill in your User Name & Company Name. Then, click “ Next “. Contact Information...
- Page 13 MP-878D User’s Manual Please select Install in this page .
- Page 14 MP-878D User’s Manual Click “ Continue Anyway “ when you see the following message. Contact Information...
- Page 15 MP-878D User’s Manual Click “ Continue Anyway “ when you see the following message.
- Page 16 MP-878D User’s Manual Click “ Continue Anyway “ when you see the following message. Contact Information...
- Page 17 MP-878D User’s Manual Click “ Continue Anyway “ when you see the following message.
- Page 18 MP-878D User’s Manual Click “ Continue Anyway “ when you see the following message. Contact Information...
- Page 19 MP-878D User’s Manual When the following message appears, click “ Finish “ to complete the installation and restart Windows or your computer.
-
Page 20: Sample Program
MP-878D User’s Manual 1.7<Sample Program> When you completed hardware & software installation, you can use COMMELL “TCCVDCApp” sample program to test. You can find TCCDVCApp.exe on desktop. Please double –click “ TCCDVCApp.exep , It’ll pops up as following. Then Please Push “ Preview “ on the left-upper Menu. - Page 21 MP-878D User’s Manual You ‘ll get the program interface as following.
- Page 22 MP-878D User’s Manual Explanation of Sample program function Device ID: It is mean BT878l Chipset. Channel ID: Support Video input per device. Snapshot: Catch the image on working channel. Callback Test: Catch the series image on working channel Note: Every channel is work separately, when you want to change any setting, please stop all channels which working.
-
Page 23: Contact Information
Taiwan Commate Computer Inc. Address 8F, No. 94, Sec. 1, Shin Tai Wu Rd., Shi Chih Taipei Hsien, Taiwan +886-2-26963909 +886-2-26963911 Website h ttp://www.commell.com.tw E-Mail i nfo@commell.com.tw (General Information) t ech@commell.com.tw (Technical Support) Commell is our trademark of industrial PC division...
