MP-6100E
User's Manual
Edition 1.0
2013/3/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP-6100E and is the answer not in the manual?

Questions and answers

Related Manuals for Commell MP-6100E

Summary of Contents for Commell MP-6100E

  • Page 1 MP-6100E User’s Manual Edition 1.0 2013/3/12...
  • Page 2 MP-6100E User’s Manual Copyright Copyright 2009 all rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.

  • Page 3: Packing List

    MP-6100E User’s Manual Packing List: Hardware: MP-6100E Mini-PCI Capture Card x1 Cable kit: Video Cable 4-ch BNC Cable x 1 D-SUB 9 Cable x 1 (OALBNCE4) (OALDB9-H15) Audio Cable (option) Dual DB9 Cable x 1 (option) Audio Cable x 1 (option)

  • Page 4: General Specification

    MP-6100E User’s Manual 1.0 <Product Specification> General Specification Form Factor Mini-PCI Type-III B H.264 Hardware compression technology Compression Format Cable kit 1 x 15-pin hirose to D-sub 9 Cable 1 x D-sub 9 to 4 x BNC connector Cable 1 x 15-pin hirose to Dual D-sub 9...
  • Page 5 MP-6100E User’s Manual 1.2 <Mechanical Drawing>...
  • Page 6 MP-6100E User’s manual 1.3 <Connector Reference> Connector: CN_AV Type: DF14-15S-1.25C Hirose Description Description Video1 Video2 Video3 Video4 Audio1 Audio2 Audio3 Audio4...
  • Page 7 MP-6100E User’s Manual 1.4 <Driver Setting> 1. Insert the driver CD into your system’s CD-ROM to Set up MP-6100E Spct6100_Directshow_SDK_V0.9.0.11.exe. (E:/Driver/MP-6100E/Windows/Spct6100_Directshow_SDK_V0.9.0.11.exe) Please select “Next” to continue.
  • Page 8 MP-6100E User’s manual 2. Please read the following License Agreement. Press the Page Down key to see the rest of agreement and click “Next” to continue the installation. Please select file location. Then, click “Next”.
  • Page 9 MP-6100E User’s Manual 4. Please select “Next” in this page. 5. Please select “Install” in this page.
  • Page 10 MP-6100E User’s manual 6. Please Click “Continue Anyway”, when you see the following message. 7. Please Click “Continue Anyway”, when you see the following message.
  • Page 11 MP-6100E User’s Manual Please click “Finish” to complete the installation. 9. Please click “Yes” to complete the installation and restart Windows or your computer.
  • Page 12 MP-6100E User’s manual 1.5 <Sample Program> 1. When you completed hardware & software installation, you can use COMMELL “Surveillance-V0.9.0.11” sample program to test. (You can find Surveillance-V0.9.0.11.exe on desktop.) 2. Please double –click “Surveillance-V0.9.0.11.exe”, It’ll pops up as following. Then Please Push “Run” on the Menu.

  • Page 13: Contact Information

    19F., No.94, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei City 22102, Taiwan Address +886-2-26963909 +886-2-26963911 Website h ttp://www.commell.com.tw i nfo@commell.com.tw (General Information) E-Mail t ech@commell.com.tw (Technical Support) Facebook https://www.facebook.com/pages/Taiwan-Commate-Computer-Inc/547993955271899 Twitter https://twitter.com/Taiwan_Commate Commell is the trademark of Taiwan Commate Computer INC.
