- Page 1 00-0634 120’ Ford Focus Kombi 1999»2004 620-1200...
- Page 2 rev. 2014-04-04 DC...
- Page 3 Congratulations on purchasing an ATS towbar Alexo Towbars Sweden offer quality towbars produced as a result of direct market research. Every towbar is sold with a unique 5-year guarantee which covers the functioning of the towbar system. Detachable towbars are to be removed when not used for towing, a common result of not removing the towbar during longer periods of time is oxidation of the inner mechanical parts, which causes the towbar to “stick”...
- Page 4 620-1200 Included Material Inkluderat material Elementos de unión de la bola Fixing items of the coupling head 2x M10 Delar för dragkrokens fäste. Elementid i unione della sfera 1x 10 x 65 (8.8) Befestigungselemented er Kugel 1x 10 x 70 (8.8)
- Page 5 Towbar installation diagram Dragkrok installationsdiagram...
-
Page 6: Fitting Instructions
620-1200 Fitting instructions 1. Dismount the bumper and the reinforcement material. 2. Using the adhesive washers place M10 nuts through the inside face of the pieces A and B at points . 3. Place A and B pieces introducing through the chassis holes to points 2 and join them using M10x35 bolts, plates 50x50 and M10 nuts. - Page 8 620-1200 Removal of type 1 towball Demontering av typ 1 drag Fitting of type 1 towball Montering av typ 1 drag...
- Page 9 Removal of type 2 towball Demontering av typ 2 drag Fitting of type 2 towball Montering av typ 2 drag...
- Page 10 620-1200 Maintenance of detachable towballs Underhåll av demonterbara dragkrokar...
- Page 11 © Copyright Alexo ATS This catalogue and all information within it belongs to Alexo ATS, any use of the material other than as an instruction manual is strictly forbidden and will be reported. All kinds of reproduction and /or usage of material from this catalogue is not permitted. ©...
- Page 12 T= 1200 kg D= 7,07 kN S= 50 kg...
