- Page 1 00-1898 120’ Opel Astra “H” Caravan 2004» (OBS! Sportmodeller kan kräva ytterligare kapning av spoiler) 645-102x...
- Page 2 rev. 2014-04-04 DC...
- Page 3 Congratulations on purchasing an ATS towbar Alexo Towbars Sweden offer quality towbars produced as a result of direct market research. Every towbar is sold with a unique 5-year guarantee which covers the functioning of the towbar system. Detachable towbars are to be removed when not used for towing, a common result of not removing the towbar during longer periods of time is oxidation of the inner mechanical parts, which causes the towbar to “stick”...
- Page 4 645-102x Included Material Inkluderat material...
- Page 5 Towbar installation diagram Dragkrok installationsdiagram...
-
Page 6: Fitting Instructions
645-102x Fitting instructions 1. Dismantle the rear lights and the bumper. 2. Dismantle the supports “4” from the bumper. 3. Dismantle the inside bumper piece. (It will no longer needed). 4. Introduce towbar through the chassis holds and fix at points 2 using M10x35 bolts, flat washers and spring washers. - Page 8 645-102x Removal of type 1 towball Demontering av typ 1 drag Fitting of type 1 towball Montering av typ 1 drag...
- Page 9 Removal of type 2 towball Demontering av typ 2 drag Fitting of type 2 towball Montering av typ 2 drag...
- Page 10 645-102x Maintenance of detachable towballs Underhåll av demonterbara dragkrokar...
- Page 11 © Copyright Alexo ATS This catalogue and all information within it belongs to Alexo ATS, any use of the material other than as an instruction manual is strictly forbidden and will be reported. All kinds of reproduction and /or usage of material from this catalogue is not permitted. ©...
- Page 12 T= 1700 kg D= 9,50 kN S= 75 kg...
