Summary of Contents for Alexo Sweden 658-091
- Page 1 00-0423 120’ Seat Toledo 1996»1999 658-091...
- Page 2 rev. 2014-04-04 DC...
- Page 3 Congratulations on purchasing an ATS towbar Alexo Towbars Sweden offer quality towbars produced as a result of direct market research. Every towbar is sold with a unique 5-year guarantee which covers the functioning of the towbar system. Detachable towbars are to be removed when not used for towing, a common result of not removing the towbar during longer periods of time is oxidation of the inner mechanical parts, which causes the towbar to “stick”...
- Page 4 658-091 Included Material Inkluderat material...
- Page 5 Towbar installation diagram Dragkrok installationsdiagram Elementos de unión de la bola Fixing itemso ft he coupling head 2x M10 Elementsd ef ixationd el a boule Elementid i unione della sfera Befestigungselemented er Kugel 1x 10 x 65 (8.8) 1x 10 x 70 (8.8) Elementos ques e aportan Provided items Elementsj oints...
-
Page 6: Fitting Instructions
658-091 Fitting instructions 1.Remove from the inside of the trunk, the trunk lining of each light compartement. 2. Dismount the bumper removing two M8 bolts from the inside of the trunk (on the front), two bolts from underside, one at each side of the chassis and three bolts from the end of the underside of the chassis. - Page 7 Stötfångarens mitt 70 mm 90 mm Stötfångarens mitt 240 mm Stötfångarens kant Stötfångarens kant...
- Page 8 658-091 Removal of type 1 towball Demontering av typ 1 drag Fitting of type 1 towball Montering av typ 1 drag...
- Page 9 Removal of type 2 towball Demontering av typ 2 drag Fitting of type 2 towball Montering av typ 2 drag...
- Page 10 658-091 Maintenance of detachable towballs Underhåll av demonterbara dragkrokar...
- Page 11 © Copyright Alexo ATS This catalogue and all information within it belongs to Alexo ATS, any use of the material other than as an instruction manual is strictly forbidden and will be reported. All kinds of reproduction and /or usage of material from this catalogue is not permitted. ©...
- Page 12 T= 1430 kg D= 7,39 kN S= 80 kg...
